| Cabin | ZZ3257M3847W |
| HW76 cab. Original luxury Volvo cab with two seats, Asleeper and an A/C. photo for your reference. |
| Vehicle Main Dimensions | L×W×H(mm) | 8545×2496×3386 |
| Wheel track(mm) | 1830 |
| Wheel base(front/rear) (mm) | 3825+1350 |
| Approach/Departure angle(°) | 19/23 |
| Weight in KGS | Tare Weight(kg) | 12400 |
| Loading Capacity(kg) | 40000 |
| Front axles loading capacity(kg) | 1×8000 |
| Rear axles loading capacity(kg) | 2×8500 |
| Max.Drinving Speed (km/h) | 80 |
| Engine | Brand | SINOTRUK |
| Model | WD615.87 |
| Type | 6-cylinder in-line with water cooling;
4-stroke direct injection;
turbo-charging and inter-cooling |
| Horse Power(HP) | 290HP(option:266hp/336hp/ 371hp) |
| Emission Standard | Euro II |
| Axle | HC16 design overall cast steel axle. |
| Gearbox | HW15710.10 block transmission, Ten Forward &Two reverse. |
| Clutch | Reinforced diaphragm spring clutch, diameter 430mm |
| Steering Gear | ZF8098,original made in German. Power steering, hydraulic steering with power assistance. |
| Fuel Tank(L) | 300L |
| Tire | Eleven units of 12.00-20 Nylon tires.(option:12.00R20) |
| Brakes | Service brake: dual circuit compssed air brake
Parking brake: spring energy, compssed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake |
| Dump Body |
| Thickness | Side | 4mm in high tensile strength steel Q345B |
| Front | 4mm in high tensile strength steel Q345B |
| Bottom | 8mm in high tensile strength steel Q345B |
| Dump Body Size | L×W×H | 5800mm×2300mm×1500mm |
| Tipping Hydraulics | Tipping Type | Front tipping type |
| Tipping System | Complete set of Local brand front tipping type hydraulics system |
