Sinotruk Cdw Light Dump Truck with 4X2 Driving Type

Sinotruk CDW Light Dump Truck With 4x2 Driving Type

Parameter
SINOTRUKCDW 4X2 DumpTruck
DrivingType				4x2
Model				CDW3160A1N4
Engine	Model			YC6J190-33
	Horsepower			190HP
	MaximumoutputKw/r/min			140/2500
	MaximumtorqueN.m/r/min			1400-1700rpm
	Type			vertical,in-line,4-stroke,water-cooled,directinjection
	Displacement			6.494L
	MakeYUCHAI, EURO IIIemissionstandard
Cab	M60, Single bed,semi-suspension. with air conditioner. width:2260mm
Clutch	SINOTRUKΦ395
Transmission	8JS85F transmission,8forwardand2reverse
FrontAxle	153 front axle, ( 6.5T)
Steering	5T power steering
RearAxles	457 rear axle (13T);speed ratio:6.33
BrakeSystem	dualcircuitcompssedairbrake
Tyres	11.00R20 Tyre with 1 Spare tire
OilTank	250 LAluminum alloy tank
Dimensions	Overalllengthxwidthxheight7550×2500×3080mm
	Wheelbase3800
Dump body/Carriage	dimension(mm)			4500*2300*1200mm
	SteelthicknessofCarriage(mm)			Floor:6mm/Side:4mm
	HydraulicLiftofCarriage			middlelifting
Weight(kg)	Curbweight 7900
	Grossvehicleweight 16000
Performance	Maximumdrvingspeed(km/h)80
Packing	NudePack.Thepackingofthecommodityshallbeinaccordancewiththeexportstandardpackingofthemanufacturer
	besuitableforlongdistancetransportationofoceanandinland.
Themanufacturerreservestherightoftechnicalalteration/changeforbetterimprovementwithoutpriornotice

COMPANY PROFILE:




TRANSPORTATION:


OUR ADVANTAGE:
(1)Competitive Factory Price and Excellent Quality
(2)More than10 years' experience as amanufacturer
(3)Products Quality Certification SGS CCC ISO
(4)Perfect after-sale service
(5)Customized products available with us
(6)Export to more than 50 countries and regions
AFTER SERVICE:
LOYOGROUP PROMISE:We are always at your service to help purchase any spare parts and ship to our clients as per client's requirement.
(1)For axles, the guarantee period is one year or 150,000 kilometers. Free maintenance is only for main parts of axle: axle beam, hub, and camshaft; excluding easy worn-out parts.
(2)For chassis, the guarantee period is one year and the trailer must carry the Tons according to the standard capacity; If the problem caused by overload, we will not be responsible.
(3)For Suspension, the guarantee period is 6month.
(4)For Kingpin, the guarantee period is one year.
(5)For landing gear, the guarantee period is one year.
