A tow truck is distinct from a motor carrier that moves multiple new or used vehicles simultaneously in routine transport operations.
| Description | ISUZU 4x2 Light Duty Road Wrecker trucks | ||
| Vehicle Main Dimensions | Dimensions(L xW xH)mm | 7250x2300x2350 | |
| Wheel base (mm) | 3800 | ||
| Overhang (front/rear) (mm) | 1015/2420 | ||
| Wheel track (front/rear) (mm) | 1504/1425 | ||
| Approach/Departure angle(°) | 24/12 | ||
| Weight in KGS | GVW. | 7300 | |
| Curb Weight | 4600 | ||
| Max. driving speed(km/h) | 100 | ||
| Engine | Model | CY4102 | |
| Type | 4-stroke direct injection , 4cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 120 | ||
| Emission standard | Euro 3 | ||
| Gearbox | 6 forwards &1 reverse | ||
| Tire | 7.50-16; 6 pieces+1 spare tire | ||
| Operation control system | Electrically hydraulic control | ||
| Platform Organ | Length(mm)×Width(mm) | 5400x2300 |
| Operating stroke(mm) | 2680 | |
| Min. angle of slope(°) | 8 | |
| Rated loading weight(kg) | 3000 | |
| Rated winch traction weight(kg) | 3500 | |
| Length of steel wire rope(m) | 21 | |
| Ground clearance of cage floor) | 470 | |
| Hoisting Organ | Max. length of extended boom(mm) | 1300 |
| Rated lifting weight(kg) | 2500 | |
| Max. extended lifting weight(kg) | 1250 | |
| Rated traction weight(kg) | 7100 | |
| Elevation of boom (upper/ lower)(°) | 9~-10 | |
| Optional Equipment | Hydraulic clamp Electric motor saw Searchlight | |
ChengLi Special Automobile Co.,Ltd, appointed by the Ministry of Industry and Information Technology of China, is one of the biggest special truck manufacturer in China.
1.We maintain a long and interactive cooperation relationship with our chassis suppliers, such as DONGFENG, FAW, SINOTRUK, FORLAND and etc;
2.Capacity of production of more than 300 kinds of special trucks and semi-trailers, higher standard is always what we pursuit;
3.Exportation to more than 68 countries, such as Africa, South-east Asia, Australia and etc, reliability and good quality are our key points to gain our customers' reputation.
Our Service
1. Special Truck Manufacturing: Dump Truck, Sewage Suction Truck, LED Advertising Truck, Ice Cream Truck, Refrigerator Truck ...
2. Pressure Vessel Manufacturing: LPG,Liquid Ammonia,Dimethyl ether,Isobutane,Propylene
3. We will reply you for your inquiry in 24 hours.
4. After sending, we will track the products for you once every two days, until you get the products. When you receive the goods, test them, and give us a feedback.If you have any questions , contact with us, we will provide technique solutions for you.
FAQ
Q1: What is your terms of payment?
A: T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2. What is your terms of delivery?
A: FOB, CFR, CIF
Q3. How about your delivery time?
A: Generally, it will take about 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the customer’s requirements?
A: Yes, we can produce by your requirements or technical drawings.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
