| Model | EG2020ASZR-01 | EG2020ASZR-02 | EG2020ASZR-04 |
| System | 48V/5KW AC system | 48V/5.3KW Sepex | 48V/5KW ACsystem |
| Unit Price (FOB Shanghai)(based on FCL) | | | |
| Key Components | | | |
| Battery | 8PCSxT105(185Ah@5hr rate) | 8PCSxT105(185Ah@5hr rate) | 8PCSxT105(185Ah@5hr rate) |
| Motor | 5KW Chinese motor | 5.3KW Chinese motor | 5KW Chinese motor |
| Controller | Curtis 1236 (400A@2minutes) | Curtis 1268 (400A@2minutes) | Zapi ACE2(400A@2minutes) |
| Performance | | | | | |
| Passenger capacity | 4 | 4 | 4 |
| Range (loaded) based on flat road at aspeed of 20km/h (km)* | 100 | 80 | 100 |
| Max.Speed(km/h) | 40 | 40 | 40 |
| Minimum turning radius (m) | 3.5 | 3.5 | 3.5 |
| Max.Climbing ability (loaded) | 20% | 20% | 20% |
| Max.Movement after brake at speed of 20km/h | ≤4m | ≤4m | ≤4m |
| Max.Loading weight | 300kgs | 300kgs | 300kgs |
| Net weight | 620kgs | 620kgs | 620kgs |
| Dimensions | | | | | |
| Overall dimensions (mm) | 3015*1290*2060 | |
| Min.Ground clearance (mm) | 120 | |
| Wheelbase (mm) | 1700 | |
| Front wheel tread (mm) | 855 | |
| Rear wheel tread (mm) | 975 | |
| Detailed Configurations:("S" stands for Standard configuration and "O" stands for Optional configuration) | |
| Body and frame | | | | | |
| frame | Welded steel framework with phosphate+electro-coating treatment | |
| Body | PP plastic front body +PP plastic rear body | |
| Roof | Fiberglass(2P Roof) | |
| Fiberglass(4P Roof) | |
| Roof handle | | | | |
| Windshield | One-piece Laminated glass | |
| Wiper and water tank | / | | | | |
| Roof frame | Carbon Steel, powder coating | |
| 3point seat belt | / | |
| Large Seats: | | |
| 1) backrest and cushion | Rebond seat +artificial leather | |
| 2) armrest | Formed | |
| 3) plastic seat bottom | | |
| Formed seat&backrest vinyl | Exclude rear flip-flop seat cushion | |
| Backrest cover in wood finish | | |
| Floor | Rubber | |
| Dashboard in black plastic | Forward/reverse switch, battery capacity indicator, ignition key | |
| Dashboard in wood finish | | |
| Steering wheel in wood finish | | |
| Beverage holders | 4 cups drink holders | |
| Glove box | | |
| Glove box door (include two locks) in black plastic | 2 doors per set | |
| Glove box door (include two locks) in wood finish (inside and outside) | 2 doors per set | |
| Side trim | Aluminum | |
| Score card holder | On steering wheel | |
| Towing bracket | On front of golf car | |
| Side rear view mirror | Two pieces per cart | |
| Battery watering system,48V system | Without water supply tool | | | | |
| Manual Pump | Water supply tool (other water supply tools are available) | |
| Electric system | | |
| Lighting system and horn | 2 headlights, 2front turn signals, 2taillights( each combined 1brake light with 1turn signal), with DC-DC converter (converting from 48V to 12V), horn.All lights with E-mark | |
| Reversing alarm | | |
| Meter | Speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator | |
| 12V accessory plug | To be mounted on the dashboard | |
| Hour meter | | |
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A | |
| Steering and Suspension | | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function | |
| Brake System | 4-wheel hydraulic brake, front and rear drum brake, with hand parking brake | |
| Accelerator | Stepless speed change | |
| Suspension system | Front and rear plate spring +cylinder hydraulic shock absorber | |
| Driving mode | Rear axle two stage deceleration, motor direct driving | |
| Rear axle | Integrated, Gear ratio12.49:1 | |
| Wheel &Tyre | 12x7 Steel rim, 24*8-12 tyre | |
| 12x7 Steel rim, 25*8-12 tyre | | | |
