Liugong Hold Cheap Price New small co
ncrete mixer truck YZH5253GJBHW
1. Driving type: 6*4
2. Drum volume: 13.4m3
3. Engine power 247KW China III emission
CHASSIS
Chassis Model DELONG SX5255GJBJR364
Emission Stage CHINA 3
Engine Power 247KW
Engine Displacement 9.726L
Driving Type 6× 4
Wheelba
se 3625+1350mm
Max. Running Speed 77km/h
Min. Turning Radius 19 m
Brake type Air pssure of double loop
Truck loading capacity 12070 kgs
DRUM
Drum material Baosteel B520JJ
Drum volume 13.4 m³
Drum loading capacity 8 m³
Drum agitating volume 5 m³
Material charge speed ≥ 3 m³ /min
Material discharge speed ≥ 2.7 m³ /min
Material discharge co
ntrol Manual
Drum remnant ratio of discharging ≤ 0.5%
Drum rotating speed 0-18 (r/min)
Drum tilt angle 13°
HYDRAULIC SYSTEM
Hydraulic pump Sauer KPV23-674R
Hydraulic pump type Piston pump
Hydraulic motor Sauer KMF23-516-50
Speed reducer Sauer TMG61.2
Hydraulic circuit type closed circuit cycle
Hydraulic tank capacity 20L
Water tank capacity 450 L
DIMENSIONS&WEIGHT
Overall Length 8850mm
Overall Width 2496 mm
Overall Height 3780 mm
Truck gross Weight 25000 kgs
Truck net weight 12800 kgs
DIMENSIONS&WEIGHT
Overall Length 8850mm
Overall Width 2496 mm
Overall Height 3780 mm
Truck gross Weight 25000 kgs
Truck net weight 12800 kgs
| Type | Model | Unit | G15SX |
|---|
| Performance of mixing drum | Geometric volume | m³ | 23.5 |
| Mixing volume | m³ | 15 |
| Maximum diameter of drum body | mm | 2432 |
| Length of mixing drum | mm | 7009 |
| Angle of inclination | ° | 10 |
| Rotating speed | r/min | 0~14 |
| Charge speed | m³/min | ≥3 |
| Discharge speed | m³/min | ≥2 |
| Residue ratio of discharge | % | <0.7 |
| Range of slump | cm | 5~21 |
| Hydraulic system | Oil pump | | international brand |
| Motor | | international brand |
| Reduction gears | | international brand |
| Hydraulic circuit | | Closed type |
| Water supply | water tank capacity | L | 450 |
| Way of water supply | | Pneumatic |
| Complete machine | Brand of chassis | | NAC |
| Chassis model | | SX5315GJBJT346 |
| Type of driving | | Left-hand drive |
| Curb weight | kg | 17000 |
| maximum gross weight | kg | 31000 |
| Type of drive | | 8×4 |
| Wheel base | mm | 1800+3375+1400 |
| Tyre | | 12.00R20 |
| Means of power takeoff | | Power takeoff by flywheel |
| Notice model | | XZJ5310GJB2 |
| External dimensions | (length×width×height)mm | 11910×2500×3995 |
| Engine | Model | | WP10.375/WP10.380E32 |
| Rated power | Kw/r/min | 276 |
| Displacement | L | 9.726 |
| Emission standard | | GB III |
