Xcm Trailer Concrete Pump Truck (HBTS90x18)

about US:
As a leading Chinese machinery and truck exporter, wehave a professional experience of 8yearsin this field. Besides our trucks ofhigh quality, our international sales team will also provide youexcellent logistics service and after-sales service. We will always do our best to solve all the problems and put our customer's interests in the first place.

We can supply:
1) ALL kinds of trucks.
(Dump truck, mining dump truck, tractor truck, truck trailer ,towing truck , water tank truck, concrete mixer truck, oil tank truck, garbage truck, cargo truck, port terminal tractor, refrigerated truck, truck mounted crane, fire truck, suction sewage truck, bus, etc)
2) All kinds of construction machinery.
(Wheel loader, excavator, folklift, cranes, paver, road roller etc.)


XCM Trailer Concrete Pump(HBTS90x18)

Operating weight:7546kgkg Engine model:6CTAA-C250 Engine power:198/2000kW/r/min Water tank capacity:100L

Item			Unit
Model				HBTS90x18
Displacement		Low pssure	m3/h	90
		High pssure	m3/h	50
transmission pssure		Low pssure	MPa	10
		High pssure	MPa	18
S valve change number		Low pssure	cycle/min.	27
		High pssure	cycle/min.	14
Transport cylinder inner diameter × stroke			mm	φ200×1800
Main cylinder inner diameter × stroke			mm	φ150×1800
Valve form				S Valve
Hopper volume			m3	0.65
Products outlet diameter			mm	φ180
Maximum allow aggregate diameter			mm	40
Engine	Model			6CTAA-C250,6CTAA8.3-C260
	Engine power		kW/r/min	198/2000,196/2000
Hydraulic system	Main system form			Open style
	Main pump		ml/r	260
	oil tank capacity		L	600
Dimension	L		mm	6960
	W		mm	2100
	H		mm	2770
Switch form of high and low pssure				Auto
Water tank capacity			L	100
Oil tank capacity			L	210
