Beiben 16 cbm Self Loading Co
ncrete Mixer Truck in Dubai
V3-BY:The overall designing of the vehicles is fashio
nable and pleasing to the eyes. The brand characteristic V finds its way into the designing of the front side, adding up to the grandeur and solemn air. The brand new V3 driving cab is created cooperatively by the company and European famous designing company. The internal instrumental panel is in the rounda
bout style popular in Europe, pleasing to the eyes. Interior trimming is made of im
ported materials with no peculiar smell, which ensures the health of drivers and passengers. The structure of me
tal f
ramework and stressed-skin exclusive to the domestic heavy-duty trucks makes possible the security of European vehicles at the same level, and can satisfy the requirements of European ECER29 Security Regulations. The vehicle f
rame is molded by stamping and this guarantees the strength of the crossbeams. The axle technique unique tofamous vehicles boasts of features such as high reliability, fuel economy, high attendance rate, large mixing volume of tanks which matches the engines with large horsepower, all making it suitable for use in all kinds of co
nstruction sites.
Oriemac Machinery & Equipment ( Shanghai ) Co., Ltd. is one of the leading suppliers of heavy co
nstruction machinery in China for more than ten years. Our brands include SANY, ZOOMLION, LIUGONG, Changlin, etc.
Our products cover:
1. Hoisting machinery ( truck cranes, mobile cranes, tower cranes, etc. )
2. Earth-moving machinery ( wheel loaders, excavators, bulldozers, etc. )
3. Road co
nstruction machinery ( road rollers, graders, cold milling machines, etc. )
4. Drilling machinery ( rotary drilling machine, road heater,etc.)
5. Special vehicle ( dump truck, tractors, forklift, reach stackers, etc.)
Specifications for Your Reference:
| 3138BY /8×4/1500+3850+1450/Long-Flat Roof Cab |
| Dimension | 10950*2500*3990mm |
| Approaching angle/Departure angle | 16/15° |
| Overhang(front/rear) | 1515/2685mm |
| Wheel base | 1500+3850+1450mm |
| Max speed | 90km/h |
| Curb weight | 16825kg |
| Loading capacity | 14045kg |
| Slope climbing capability | Max.40% |
| Engine | Model | WP10.375,water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection |
| Displacement | 9.726L/Diesel |
| Stroke | 126/130mm |
| Max. power | 276/2200 (kw/rpm) |
| Max.torque | 1460/1200-1600(Nm/rpm) |
| Emission stantard | Euro III |
| Fuel tanker capacity | 300L |
| Clutch | 430, Single dry frictional disc,Hydraulic boosting |
| Gearbox | 9T-180mechanism,9 forward gears,1 reverse gear, manual operated, with synchronizer |
| Gear ratio of gear box | 12.82/7.93/6.00/4.43/3.43/2.31/1.75/1.29/1.00 R: 11.21 |
| Suspension system | Front | Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension , 10pcs |
| Rear | Non-free standing stablization spring, balance suspension system, 13pcs |
| Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system |
| Assistant brake | Engine exhaust brake |
| Park brake | Potential springs pssing on middle and rear wheels |
| Steering system | TAS85,whole circulation in ball, hydraulic booster |
| frame | Fish belly shape, variable width, variable sections |
| Front axle (German Technology) | Double-shoe pneumatic brake, non-driving steering axle |
| Middle and Rear axle (German Technology) | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle |
| Tyre | 12.00R20 Radial |
| Electrical system | Battery | 2X12V/135Ah |
| Generator | 28V-35A |
| Starter | 5.4Kw/24V |
| Cabin | V3 Long-Flat roof cabin with single sleeper
Full steel skeleton structure, covered with double layer steel plate;
Can be tipped forwardly;
High back seat for driver;Electric lifting window ;
With inner A/C |
| Main technical parameters of concrete mixer |
| Drum performance parameter | Geometric Volume m3 | 26.1 m3 |
| Effective Volume m3 | 16 m3 |
| Filling Ratio % | 61.30% |
| Gradient of the Drum ° | 9° |
| Filling speed m3/min | ≥3 |
| Discharging Speed m3/min | ≥2 |
| Surplus Ration % | <1% |
| Range of Slump mm | 20~300 |
| Hydraulic System | Pump | Eaton 64 (ACA642337) |
| Motor | Eaton 64 (HHD6423321) |
| Gear Box | PMB7.8SP |
| Water supply system | Volume of water tank | 400L |
| Water supply type | Air pssure Type |
