12CBM Concrete Mixer Truck 6*4 (12M3)

12CBM Concrete Mixer Truck 6*4

1. Mixing capacity 12m3 (6M3~14M3 is available)

2. Engine Power 340HP

3. Truck Chassis DFAC Brand (You can also choose HOWO, ISUZU, etc. )

4. RHD (Right Hand Drive) is available
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic pheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart pvention system effectively avoids the misoperation, and improve the use security of the machine.

Chassis	Chassis Brand		Dongfeng
	Chassis Model		EQ1252GSJ3
	Drive Mode		6*4
	Tire		11.00R20
	Brake		Air brake
Engine	Model		YC6M340-33
	Horsepower (Hp)		340
	Displacement(ml)/Power(kw)		9839/250
	Emission		Euro III
Main Parameter	Overall dimension (mm)	Approx. L*W*H	9650*2500*3800
		wheelbase	4000+1350
		Axles No.	3
	Weight (KG)	Gross weight	25000
		Payload weight	12000
		Kerb weight	13000
	Leaf spring No.		9/10
	Front/Rear Trace(mm)		1986/1860
	Max speed(km/h)		80
	Gear Box		9 speed gearbox
	Front/Rear Axle Load		5T/13T
	Stirring Volume(M 3 )		12
	Filling Rate(%)		63%
	Rate of Feeding(M 3 /min)		≥ 3
	Rate of Delivery(M 3 /min)		≥ 2.0
	The Remaining Rate(M 3 /min)		≤ 1.0
	Tube Service Speed(r/min)		0-12
	Tube Dip(° )		13-15
Hydraulic Drive Parameters	Oil Pump		Italy or Germany Brand
	Hydraulic Motors
	Decelerator
