Small Tricycle of 850W 48V Three Wheel Electro Tricycle Sale

Our company will offer you the high quality products with a low price, quick delivery,and professional after-sale service.
Small tricycle of 850W 48V Three Wheel Electro Tricycle for Sale
The refrigerator truck is mainly used for terminal distribution of vegetables and fruits.
Configuration parameters of canopy insulation vehicle:

S/N	Component name	Parameter values / specifications	Remark
1	Appearance image	Prepare in accordance with the enterprise recognized VI image	The enterprise provides VI design / design pictures
2	Load capacity (excluding driver)	≥300Kg
3	Full charge endurance	≥50Km
4	Gradeability	>15°	No load
5	Maximum speed	≤35Km/h	Driver included
6	Vehicle weight	≤270kg
7	Reverse speed	≤12Km/h
8	Battery type	Lead acid battery
9	Battery capacity	20ah - 50ah	Optional
10	Nominal voltage	48V
11	Motor	800W	Optional
12	Voltage	48v
13	Controller	48V18 pipe, matching with motor (speed Lida)	Voice reversing, undervoltage protection, voice self-checking
14	Line	GB high temperature resistant line (120 degrees high temperature, low temperature -20 degrees)
15	Tire	Front / rear: 3.00-12; 3.00-12 (2mm load bearing solid hub)
16	frame	Integral bending beam with keel and bracket	frame electrophoresis, inside and outside pipe antirust treatment process
17	Back box bearing leaf spring	5 load bearing and thickening leaf springs	Soft connection, more comfortable
18	Front fork damping	Hydraulic damping	The whole vehicle has good damping effect and good elasticity
19	Guard plate	The frame is provided with front fork guard plate for driver
20	Fender	Three tires are fitted with fenders or mud guards
21	Seat	Both sides of guardrail, single toilet	The width is sufficient for 2 people
22	logo	Prepare in accordance with the enterprise recognized VI image	Outdoor sunscreen
23	Specification requirements	Cargo carriage, the carriage can be lifted flexibly	Outdoor sunscreen, good sealing, no seepage rain phenomenon
24	Door opening direction	Right door opening	Double doors in the back and sides
25	Door opening size	Width 900mm* height 700mm	Bigger and more convenient
26	Door anti-theft design	Lashing bar lock	Carriage door with sealing strip
27	Color	Customizable according to the customer's requirements
28	Sunshade and rainproof awning material	Iron plate (>0.8mm) +3C certified toughened glass (>3.5mm)	Overall design has the advantages of good sealing, outdoor sunscreen and rust pvention
29	Rearview mirror	The lengthened type ensures the rear view of the rear carriage and the surrounding
30	Vehicle size	2800mm*1000mm*1650mm (length * width * height)
31	Carriage size	1500mm*1000mm*1000mm (length * width * height)	Reasonable width and better stability
32	Vehicle weight	about 235kg

FAQ
1: What kind terms ofpaymentcan be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: Whatcertificatesare available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about thedelivery time?
A: 30 days after receiving the deposit.
4: What about thewarranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about theMinimum Order Quantity?
A: The MOQ is 1 pcs
