Compssed Garbage Truck
It is the special dump truck equipped with hydraulic lifting mechanism and tail packer to compact the garbage, load, transfer and dump the garbage automatically.
sinotruk howo rear loading compactor garbage truck
| SINOTRUK HOWO 4*2 Compssed Garbage Truck |
| Driving Type 4x2 |
| Chassis Model | ZZ1167M4611 |
| Engine | Model | WD615.47 |
| Horsepower | 266 |
| Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection |
| Displacement | 9.726L |
| Make SINOTRUCK (CNHTC), Euro II emission standard,Rigid fan |
| Cab | HW70 HOWO long cab, with two seats, one bed, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts,adjustable steering wheel, air horn,air conditioner , with transverse stabilizer,with 4-point support fully floating suspension + shock absorber |
| Clutch | SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance |
| Transmission | SINOTRUK HW13710CLtransmission ,12 forward and 2 reverse |
| Front Axle | SINOTRUK HF7 Front Axle,HOWO 9-ton front axles of equipped with drum brakes. |
| Steering | German ZF8098Steering Gear Box ,hydraulic steering with power assistance |
| Rear Axles | SINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles,enforced STR axle;can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice forcustomers. |
|
| Brake System | Service brake:dual circuit compssed air brake |
| Parking brake (emergency brake):spring energy,compssed air operating on rear wheels |
| Auxiliary brake:engine exhaust valve brake |
| Tyres | Tyres: 12.00R20radial tyre with 1 Spare tire |
| Electrics | Operating voltage:24V,negative grounded |
| Starter:24V,7.5 Kw |
| Alternator:3-phase,28V,1500 W |
| Batteries:2x12 V,165 Ah |
| horn,headlamps,fog lights,brake lights,indicators and reverse light |
| Carriage ( dump body ) | Overall length x width x height7350x2350x2800 (mm) |
|
| Weight (kg) | Kerb weight13000 |
| Gross vehicle weight25000 |
| Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer |
| be suitable for long distance transportation of inland and ocean. |
| The manufacturer reserves the right of technical alteration /change for better improvement without |
Our Company
The LOYO Group originated from Do
ngxing Lianyou im
port & Export Co,.Ltd. which was founded in 2008. Its headquarter locates in Do
ngxing City ,Guangxi China, which is the leading-edge of China-ASEAN border and the o
nly city co
nnecting with ASEAN area both by land and water. Our company is an authorized dealer and exporter of China Natio
nal Heavy Duty Truck Group Co., Ltd (SINOTRUK) , havin
g the auto
nomy right of im
port and export businesses . Currently we have established an excellent and professio
nal sales team and after-sales service team.
The LOYO Group's main business includes dump truck manufacturing & modification , sales and service of all series SINOTRUK(CNHTC) product including dump truck , off-road mining truck, tractor, cargo truck, co
ncrete mixer truck, water tanker ,oil tanker and other special truck and parts. Co
ncerning the mechanical power aspect, we have covered horsepower level from 90Hp to 540Hp, which can meet customers' different needs. Our target is to become a world renowned supplier and providing customers with cleaner, more energy-saving, safe, more reliable and comforter transportation vehicles.
OUR ADVANTAGE:
(1)CompetitiveFactoryPriceandExcellentQuality
(2)Morethan10years'experienceasamanufacturer
(3)ProductsQualityCertificationSGSCCCISO
(4)Perfectafter-saleservice
(5)Customizedproductsavailablewithus
(6)Exporttomorethan50countriesandregions
AFTER SERVICE:
LOYOGROUP PROMISE: We are always at your service to help purchase any spare parts and ship to our clients as per client's requirement.
For axles, the guarantee period is one year or 150,000 kilometers. Free maintenance is o
nly for main parts of axle: axle beam, hub, and camshaft; excluding easy worn-out parts.
For chassis, the guarantee period is one year and the trailer must carry the Tons according to the standard capacity; If the problem caused by overload, we will not be responsible.
For Suspension, the guarantee period is 6month.
For Kingpin, the guarantee period is one year.
For landing gear, the guarantee period is one year.
