| Engine | Make: CNHTC |
| Diesel: 4-stroke direct injection diesel engine |
| Engine model: WD615.47, Euro II emission standard |
| 6-cylinder in-line with water cooling, turbo-charging and intercooling, 4strokes |
| Maximum output: 371hp (247Kw) at 2200rpm |
| Maximum torque: 1500Nm at 1100-1600rpm |
| Number of cylinder: 6 |
| Displacement: 9.726L |
| Bore/Stroke: 126/130mm |
| Ignition Sequence: 1-5-3-6-2-4 |
| Fuel: diesel |
| Gearbox | Model: HW19712, 12F/2R, Manual Gearbox |
| Transmission Ratio Reverse: 13.81 |
| Transmission Ratio Gear 12: 1 |
| Transmission Ratio Gear 11: 1.27 |
| Transmission Ratio Gear 10: 1.63 |
| Transmission Ratio Gear 9: 2.06 |
| Transmission Ratio Gear 8: 2.67 |
| Transmission Ratio Gear 7: 3.43 |
| Transmission Ratio Gear 6: 4.38 |
| Transmission Ratio Gear 5: 5.57 |
| Transmission Ratio Gear 4: 7.14 |
| Transmission Ratio Gear 3: 9.03 |
| Transmission Ratio Gear 2: 11.67 |
| Transmission Ratio Gear 1: 15.01 |
| Max.Input Torque:1500NM |
| Cab | HW76 model cab, with air conditioner,without bunk, MP3 radio, German VDO electrical control system |
| Driving Axle | Model:HC16 |
| Central single reduction +hub reduction, casting axle housing. |
| Rated load(kg):2x16000 |
| Ratio:5.73 |
| Front Axle | Model: HF9 |
| Rated load(kg):7000 |
| Maximum steering angle of inner wheel(°):45 |
| Kingpin inclination(°):3 |
| Camber angle(°): 1 |
| Tyre | Rims: 8.5-20, 10 hole-steel |
| Tyres: 295/80R22.5 Radial Tyre, 10+1pcs |
Dimensions
(mm) | Wheel base:1800+3225+1350 |
| Front wheel track:1939 |
| Rear wheel track:1800 |
| Front/Rear overhang: 1540/845 |
| Approach/Departure angle (°):15/38 |
| Overall Diamention: 9795×2496×3070(L×W×H) |
| Weight | Permissible loading capacity:16000 |
| Chassis dead weight: 7020 |
| Front axles loading capacity:9000 |
| Rear axles loading capacity:2X16000 |
| Maximum driving speed (km/h):90 |
| Color | Color opition: red, yellow, blue, green, whit |
