Detailed Description
Production des
cription:
| Manufacturer: | MAN | |
| Wheelbase: | 4500mm | |
|
| Approach angle | 30 degree | |
| Departure angle | 30 degree | |
| Driving modes | 4×4 | |
| Roll angle | about 34 degree | |
| Engine Model | MAN D2676LF08 | |
| Efficiency | 397kW(1900r/min) | |
| Torque | 2300N.m(1000~1300r/min) | |
| Emissions standards | Euro IV | |
Transmission
| ZF 12 AS 2330 OD MAN TipMatic | |
| Clutch | | |
| The braking system | MAN Brake Matic (EBS) (ABS) | |
| Electrical system | Generator 28V/110A/3080W, Battery 2x12 V/225AH,Electric Trumpet Horn, Manual battery main switch
| |
| Dimensions | 8092mm×2500mm×3950mm | |
| The maximum speed | 110km/h | |
The minimum turn radius
| 20.7m
| |
| Acceleration Function | < 25s (from 0 to80km/h) | |
| Total Weight | 18000kgs | |
| Loading Capacity | 4600kgs water + 400kgs Foam | |
| Seating Capacity | 2 | |
| Power density | ≥22kW/t | |
| Maximumclimbing degree | ≥50% | |
| Vehicle Mounted Engine | | |
| MODEL: | L375-20, Commins | |
| Efficiency of the | 375HP/2200rpm | |
| Fire Pump | | |
| Model: | hale RSD100 | |
| Rated Flow | 100 L/S(1.0Mpa) | |
| Installation Form | Middle Type | |
| Fire Monitor | RCMF1700 | |
| Flow | Max flow 100L/s(1.0Mpa) | |
| Range | 90m(water)/85m(Foam) |
More photos for your revew:
Company information:
CIMC VECHICLE was founded by CIMC group, which fixes the mission to be customers' partner for modern transportation. CIMC is dedicated to manufacturing and supplying CIMC trucks, CIMC truck body assembly, trailers, tank equipment. Currently, CIMC owns USD 8.8 billion total assets, USD 2.6 billion net assets, USD 8.4 billion annual sales and USD 0.6 billion net profits in 2010, having over 150 subsidiaries and 63, 000 staff across China, North America, Europe, Asia and Australia.
Vehicles: CIMC has over 1000 lines of products in 11 series, including container chassis, flatbed trailer, bulk lorry, tanker, self-dumper, reefer trailer, van, curtain side trailer, mixer, pump truck, car carrier vehicle, fire engine, sanitation vehicle, etc. With the annual output capacity of over 200 thousand units, it now takes the leading position in the world. Up to today, the Group has established 22 production bases.
Heavy Truck: Have its own production C & C brand truck. Other heavy truck CIMC produces the truck body, more than 2, 000 kinds of truck body for different transportation purpose. The truck chassis cooperates with FAW, DonGFENG DFAC, SHACMAN, SINOTRUK, FOTON, BEI BEN, JAC, CAMC, SI CHUAN HYUNDAI, SAIC-Iveco and so on, include all truck chassis brand production in China.
FAQ
Q1.Areyouamanufacturer?
Yes,wehavebeenin specialvehiclemanufacturingandmarketiing for over 20 years.
Q2.Whatmarketsdoyour vehicle export to?
Europe,North&SouthAmerica,South-East Asia,Africa,Oceanica,MiddleEast countries etc.
Q3.WhatinformationshouldIletyouknowifIwanttogetaquotation?
Pleaseletusknowthe your purpose,road condition,cargo type,tons of your cargo,dimensions of trailer,quantity etc. The more info you provide, the more accurate model and price you will get.
Q4.Isitavailabletoprintourownbrandonthevehicle?
Totallyacceptableas you wish.
Q5.HowcanIgetthepriceofyourvehicle?
Youcanconnectwithusthroughanyofthefollowingcontactinformation.Ourpersonalizedservicepersonwillrespondyouwithin24hours.
Contact Information:
ZHUMADIAN CIMC HUAJUN VEHICLE CO., LTD.
Huajun Avenue, Yicheng District, Zhumadian, Henan, China
Website:www.cimc.com
Tel: 0086-396-3810953
Mobile NO.: 0086-15824916651
Fax:0086-396-3810953 Product Image
