High Quality Electric Fire Truck Dimension

4 Seaters White Electric Patrol Car with 48V/3.7kw, CE
1) Motor: US ADC brand
2) Controller: US CurTis1266
3) Battery: Trojan
Patrol Car / Electric Car / Electric Patrol Car /Electric Vehicle

Main Components:

1 Motor: ADC

1.1 Originally imported from USA
1.2 3.7KW output makes strong torque and stable performance
1.3 Temperature resistant, excellant sealing property

2 Controller: US CurTis1266

2.1 Originally imported from USA
2.2 Lots of operational modes:
A Speed Mode
B Speed-increasing Mode
C Automatic speed-decreasing Mode
2.3 Electric brake and anti-charge function

3) Transaxle

3.1 Stable quality, little noise, anti-fatigue and long durability;
3.2 There is oil seal which can bear high temperature, therefore it can pvent the transaxle from oil leakage.
3.3 Output half axle integrated together with brake chamber, such design concept is advanced.

4) Battery: US / Trojan

4.1 Trojan: T-105 6V 185AH
T-875 8V 145AH
4.2 US: US 2000XC 6V 232AH
US 8VGCXC 8V 170AH

Body& Chassis
Body	PPAlloy automatic industrial special plastic
Chassis	Welded high yield strength tubular steel with liquid painting, spray booth painting, anode cells.
Standard color	white color
Dimension
Overal length	3590mm
Overal width	1500mm
Overal height	1900mm
Ground clearance	130mm
Power
Motor	US made 3.7kw A. D. C motor
Battery	US made Trojan T-875 battery 8 volt x 6 units, 145Ah
Charger	Offboard charger or Canada made Delta-Q onboard charger
Controller	US made Curtis 1266 controller
Transaxle	Sunuptransaxle
Performance
Net weight (exclude batteries )	590kg
Loading capability	360kg
Climbing Capability	Safety climbing capability20% Max climbing capability 30%
Maximum speed	18-24 km/h
Braking distance	≤ 2.5 m
Minimum turning radius	2.9m
Max continuous mileage	80km_ 100km
Steering& Suspension
Steering	Dual automotive-style strut and self-adjust rack-and pinion steering
Front suspension	Helical spring with hydraulic shock absorber
Rear suspension	Helical spring with hydraulic shock absorber
Brakes	Dual rear wheel mechanical drum brakes, self-adjusting with non-asbsestos linings
Air pssure	22PSI
