>>>>>> REFERENCE CONFIGURATION
Here provide50 CBM bitument tanker trailer configuration for your consideration only;
Volume can be customized as needs.
45 M3 Asphalt Transport Semi Tanker Trailer | |
| Model | PLY9400GYY |
| Wheel base | 1310 (mm) |
| Tyre Specifications | 12R22.5 |
| No. Of the Tyres | 12 pcsISO Certificated |
| Axle | 13Tonnage |
| No. Of the Axles | 3 pcs |
| Landing Gear | 28 ton capacity Fuwa with static capacity of 80T |
| Suspension | Heavy duty mechanic suspension with 10 pcs leaf spring |
| King Pin | 2' and 3.5' interchangable traction pin |
| Departure Angle | 15 |
| Front/Rear Overhang | 1900 mm |
| Material of the Main Beam | Automatic submerged arc welded Main beams Q345B/ST52-3, through cross beams Q235 Body material Q235B manganese plates, automatic submerged arc welded |
| Brake System | Automatic air brakes Double pipe line air brake, front two axle is 30 air chamber, rear axle is 30/30 air chamber. |
| Colour | As the buyers' request |
| Accessory | One tooling boxes ,Two spare tire carrier, Two fire extinguisher |
| Tanker side thickness | 5mm carbon steel |
| Net Weight | 12 T |
| Oil tanker | 1000 liters Round Shape |
| Spare tire carrier | 1 set |
| Electrical System | 24V, 7core socket, lights according to European standards. |
| Tool Box | 1 box of standard tools |
| Heat Preservation System | Electrical or Diesel |
Other Dimension and rated capacity will be available, pls contact the supplier through email. Detailed quotation with your needed data will be provided. | |
