2 Axles Concrete Mixer Truck Transport Semi Trailer

1.Total Weight(kg): 25000kg
Ratedloadingcapacity:11850kg
Waterboxcapacity: 300L
Volume(m³): 10CBM
Axle Number: 3 axles
Tire Number: 12 pcs
Kingpin: 50mm/90mm
Tread: 1840mm
Color:Optional

2. Here provide the semi trailer data sheet for your consideration only:

Type	concretemixertruck
Totalweight	25000kg
Ratedloadingcapacity	11850kg
Axleno	3 axles
Wheelbase	3600+1350mm
Tirespecification	12.00-20(11pcs)
Power	336HP
Emmissionstandard	China3
Suspension	MechanicalsuspensionAmericantypelocalbrand
Mainbeam	SkeletalchassiswithspecialdesignedIbeam;optingforhightensilesteelQ345B,weldedbyautomaticsubmerged-Arcprocesses.Topflange16mm,width140mm;MiddleFlange8mmheight500mm;bottomflange16mm,width140mm
Fuelmaterial	Diesel
Maxspeed	90km/h
Feedingspeed	>=3m3/min
Outputspeed	>=2m3/min
Waterboxcapacity	300L
Mixerbodymaterial	5mmor6mmsteelplate
Tractortruckmodel	6*4or8*4

3.Other information:
Shandong Weihua import & Export Co., Ltd is a research, production and sales in one of the industry and trade enterprises. It is specialized in research, development, production of semi-trailer and special vehicles. The factory is located in the special vehicle production base -- Liangshan, China.Our company's main products are as below:Low bed semi trailer (including the trailer that can be extended to 53m)Container trailer: Skeleton container trailers & flatbed container trailersSide wall semi trailerDump semi-trailerBulk cement tank trailerOil / fuel tank trailerVan / box semi trailersemi trailer accessories. At the same time, we also operate brands of heavy trucks, tractors, engineering machinery and agricultural machinery.
Our factory has 20 years of production experience. It owns complete R&D center, vehicle and parts inspection center, rollover test laboratory, collision test place. The trailer payload is from 20 tons to 300 tons. The production capacity is over 10000 units per year.Our trailers are widely exported to Russia, Outer Mongolia, Vietnam, Philippines, the middle east, Africa (such as Sultan, Nigeria, Algeria), South America and so on.
The company always adhere to the quality first, customer supme principle for good service to every customer. Each of vehicle that we produced has a high quality and reliability. We always strive to know your business to ensure we provide you the high quality trailers and servicing more intimately. You can inquiry us for a solution to virtually and transport problems you may have. So, you can be assured of optimal operating efficiency, cost control and above all, reliability.




Whyus?
1- Since 1996, with 20yearsexperience.
2-2 years guaranteeforallthe beamoftrailers.
3-Reliability,safetyandeconomictransportsolutions.
4-Customproductionaccordingtodemand.
5-Strictqualitycontrol,out-standingqualityassurance.
6-Stocktrailersandimmediatedelivery.
7-After-saleserviceavailable,emailwillbereplywithin8hours.

OurAdvantage
1-Withwellexperiencedsemitrailerproductioncompanytoofferhighqualityandcompetitivepricessemitrailertoourworldwidevaluablecustomers.
2-Anprofessionalteamwhichisexperiencedwithinternationalmarketandhasstrongtechnicalcapabilitytocustomizedcosteffective.
3-Sellwellintheinternationalmarkets,suchasAfricanmarket(Sudan,Angola,Zimbabwe,Liberia,Djibouti,Congo,Kenya,Ghanaect.),MiddleEast,SouthAsiaandSouth-Americamarket.
4-2yearsguaranteeforallthebeamoftrailers,timelyshipment.

QualityControl
1-Foreachtrailer,weshoulddothetestingandinspectthequality.
2-Wegiveinspectioncertificateaccordingtocustomerdemandforeverytrailerwhichgivenbyanindependentthirdpartycertificationcompany.
3- We provide out-standing quality assurance.
4-Noanyqualitycomplaintsfor9years.

PerfectService&Support
1-Wheneverreliability,safetyandeconomicisneeded,thereis a solution. Weihua provides the best possible quality semi trailers to worldwide valuable customers.
2-Withafullrangeoftrailerspatepartssupport,sparepartssupplyingwithin3days.
3-Seriouslyconsidercustomer'srequirements,andwelcomedifferentcooperationmodes.
4-Provide professional trailer drawing.
5- Considerate after-sales service & product maintenance.


Shandong Weihua can supply all kinds of semi trailers, we can design and produce according to your requirements.
