40 Feet container truck factory, container trailer factory

Hot Sale China 20ft/40ft 2 Axles Container Trailer
Company information:
We're one professional manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as dump truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.


We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.



Dimensions(12390*2480*1490mm)
Total Mass40000KG
Tare Weight7900kg
Payload32100kg
Wheel base7745+1356+1356

(The above can be modified as you wish)

STANDARD SPECIFICATION

Main frame:
Heavy duty and extra durability designed; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes
500mm Height, Top Flange 16mm, width 140mm; Middle Flange 6mm; Bottom Flange 16mm, width 140mm

1)Floor:
Steel Sheet 3mm thickness

2)Axle
One Pcs of 28T Or 32T L1 Brand Bogie Axle.

3)Suspension
Bogie Suspension

4)Leaf Spring
Bogie Suspension

6) Landing Gear
Two-speed, manually operating, heavy duty landing leg, Brand: FUWA 19" Or JOST D200

7)Wheel Rim
Thirteen units of 8.25*22.5 rim

8)Tyre
Thirteenunits of 11R22.5 Tubeless tyre, One spare tyre included.

9)Twist Lock
12 sets ISO twist lock

10)Spare Wheel Carrier
One set of spare wheel carrier including a riser.

11)Pneumatic Braking System
Two unit of WABCO RE 6 relay valve; Four units of T30/30 spring brake chamber; Two units of T30 brake chamber, Two unit of reliable local brand 45L air tank; Two units of reliable local brand standard coppery air-connector.

12)Electrical System
One unit of JAEGER POWAY, 24V 7-pin ISO 1185 socket; Tail lamp with turn signal, brake light & reflector, side lamp etc.

13)Painting Sand blasting processing clean rust
1. Coat of anticorrosive primer
2. Coats of finish urethane paint
3. Color as customer choice

14)Accessory
One tooling box with whole set of standard trailer tool

Function		Load2*20ftand1*40ftcontainer
Overalldimension		12350*2480*1600mm
Maxpayload		50Ton
Curbweight		7.5Ton
MainBeam		Q345b500mmheight,upper/downplateis20/20mm,middleplateis10mm
sidebeam		160mmchannelsteel
crossbeam		100*50*6mmI-beamsteel
Platform		3mmcheckeredplate
Runningconstructon
Axle		BPW/Fuwa 13T/2Pieces/optional
tyre		12R22.5 /8pcs
rim		9.0-20/8pcs
Twistlock		12pieces-screwtype
leaf-spring		90width*10pieces*13mm/4 sets
Kingpin		interchangeable90#&50#
Landinggear		JOSTC200 /optional
suspension		Mechanical suspension
Toolbox		1pcsstandard
Sparetyrecarrier		2piecestandard
Watertank		Optional
Fueltank		Optional
Brakingsystem		with ABSsystem /WABCO optional
Electricalsystem		24voltage
		7ways(7wireharness)
Light		LEDtype
Packing		Nude,PolishwithWaxbeforeShipment
Painting		Colorisoptional
Remark		Theabovementioneddataisforyourreferenceonly. Thedetailedspecificationwillbesubjecttoourfinal/confirm/iation.
