40ft Utility trailer,semi trailer, Skeletal trailer, Truck trailer
Company information:
We're one professio
nal manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as dump truck, tanker trailer, co
ncrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.
We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to co
ntact us please.

40ft Tri-Axle Flatbed Semi Trailer Co
ntainer Truck Trailer
40ft Tri-Axle Flatbed Semi Trailer co
ntainer trailer
Trailer, Truck Trailer, Co
ntainer Trailer, Semi Trailer, Semi-Trailer, Tractor Trailer, Flatbed Trailer, Tri-Axle Flatbed Trailer, Flatbed Semi Trailer, Semitrailer, Co
ntainer Semi Trailer, Trailer Truck, utility trailer, Skeleton Trailer, box trailer, cargo trailer, trailer part, Co
ntainer Carrier Trailer, heavy truck
40ft Tri-axle Flatbed Semi Trailer
Flatbed bed co
ntainer semi-Trailer, Flatbed Semi Trailer,
Co
ntainer Semi Trailer, Semi Trailer, Semi-Trailer, Trailer and etc.

1. Tare Weight 6200kg
2. Payload 35000kg
3. Chassis: Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm, width 140mm; Middle Flange 6mm, height 500mm; Bottom Flange 16mm, width 140mm.
4. Axle: 2/3 axles of Germany design 12ton, 13 ton, 16 ton axle optio
nal upon choice
5. Brand Name: FUWA -optio
nal BPW
6. Suspension: Germany design heavy duty mechanical suspension or air suspension optio
nal upon choice
7. Floor: 3mm checker plate Leaf Spring Doll type Leaf spring
8. King Pin: JOST brand 2" Bolt-in King Pin
9. Landing Gear: JOST brand Two-speed, manual operating, heavy duty Wheel Rim 8.25-20, 9.0-20, 8.25R22.5, 9.0R22.5, 11.75R22.5 steel wheel rim optio
nal upon choice
10. Tyre: 11.00R20, 12.00R20, 11R22.5, 12R22.5 tire with one spare tire optio
nal upon choice
11. Twist Lock: 12 nos. Of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container, the retractable central locks can be laid down. Spare Tire One set of spare tire including a carrier
12. Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks
13. Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
14. Accessories One standard tool box

Product Information |
Product | container flatbedsemi trailer | |
Brand Name | HTCBrand |
Model Number | HTC9406TJZ |
Announcement (batch) | 226 |
Place of Origin | Shangdong province, China |
Color | Any color will be available |
Manufacturer | QINGDAO HETANCH TRUCKCo., Ltd |
Product Specifications |
Total Weight | 46500 kg |
Rated Load | 40000 kg |
Tare Weight | 6500 kg |
Wheel base | 6900+1350+1350 (mm) |
Tyre Specifications | 11.00R20 20PR
12R22.5 20PR (Tubeless tyre or Radial tyre) |
No. Of the Tyres | 12 |
Axle Brand | FUWA (BPW optional) |
No. Of the Axles | 3 |
Axle-load | 16000 kg |
Pieces of leaf-spring | 10 (8) |
Suspension | Independent stamping steel rigid suspension ( air suspension) |
Departure Angle | 17 |
Front/Rear Overhang | 2135 mm |
Outside Dimensions (LxWxH) | 12400x2500X1600 (mm) |
Twist lock | 8/12 pcs |
Material of the Main Beam | Q345A manganese plates, automatic submerged arc welded |
Brake System | Air braking(ABS is optional ) |
Brake Air Chamber | Four double and two single chamber |
Usage | 40ft and 20ft container |
Other Descriptions | The cargo's carring part of the stake truck is store house bar style designed, the beam wears through the longitudinal beam which is welded as a space frame structure, making the frame strength, stiffness, flexibility an equilibrium, a strong carrying capacity without permanent deformation. |
Our advantage:
1)high quality co
ntainer semi-trailer with competitive price.
2) Certification: ISO 9001 and TS16949, South African SABS-3 for co
ntainer trailer semi trailer.
3)Quick respo
nse and quotation.
4)We also like to develop new types co
ntainer semi trailer according to your special requirement
alltypessemitrailers,lowbedsemitrailer,containertransportsemitrailer,sidewallsemitrailer,storehousebarseries,vanseries,carcarriersemitrailer,dumptrailer,tankertrailerseries,concretemixertruckseriesetc.Also,ourbusinesslinerangesfromtheresearch,development,anddesigntothemanufactureandsalesforotherautomobileaccessories,especiallyfortires.OurproductsaremainlyexportedtoPhilippine,Tunisia,Vietnam,Tanzania,Angola,Mongolia,Venezuela,UAE,Kenya,ect

1)Manufacturer,morethan14yrsprofessionalexperience.
2)CCC,SGSandISO9001certificate,one year guaranteetermprovided.
3)Smallordercanbeaccepted.
4)Anycolorandlogowillbeavailable.
5)Productscanbecustom-madeaccordingtoyourdesign,ordiversifiedneeds.
More details of products and specifications, feel free to contact us please.
