The specifications below are just reference for you, we accept customizing.
| Product | Draw bar trailer series |
| Usage | For transporting ISO containers and cargos such as fruits, vegetables, pipes, ores, sand, crops etc. |
| Optional features | Detachable sides, container locks, pipe pillars, floor, front wall, hydraulic tipping system |
| Dimensions | According to customer's request |
| Wheel base | TBA |
| Tare weight | Normally 4000 to 8000 kg |
| Max. payload | 5000 to 40000 kg |
| Main beam | H-shaped beam made of high tensile manganese steel by automatic submerged arc welding
Height of 480mm, Upper plate 14mm thick, web plate 8mm thick, lower plate 16mm thick for the standard (custom production available) |
| Side beam | 6x160mm channel steel |
| Floor | 3mm thick diamond plate |
| Axle | Fuwa 13T for the standard |
| Tire | 11.00R20 as one option |
| Suspension | (German type or American type) Mechanical suspension with leaf springs |
| Turntable | Standard or as per customer's request |
| Drawing system | Standard foldable drawbar with back-moving springs and detachable towing loop DN50 |
| Brake system | Two-circuit air pssure braking with chambers T3030 & T30, Vabco relay valve, air tank. ABS: HN 4s/4m as an option |
| Electric system | 24V, 7 core wiring harness for all sets of LED lights |
| Others | Spare tire carrier * 1pcs, tool box * 1pcs, reflective stickers, side/rear guards |
| Painting | Sand blasted, then 1 layer of primer, 2 layers of paint to finish |
| Lead time | 7 days after receipt of payment |
| Expected service life | More than 10 years |
| All configurations can be modified according to customers' requirements. |
1.3C&ISO Agreement, 1Year Guarantee Term, Main-beam Lifetime Promise.
2. Small Order Can Be Accepted.
3. Any Color &Logo Available.
4. The Product Dimension +Specifications Can Be Designed As Your Request.
| Buying Guides |
| 1 | You send us your enquiry |
| 2 | We shall reply you with the quotation within 24 hours |
| 3 | We negotiate on the configuration that you need |
| 4 | Confirmation of the tech data →sign contract (P/I) →30% deposit (or L/C issuing)→ production |
| 5 | Manufacturing process updated news →completing production |
| 6 | Balance payment →ex works →shipment →custom clearance →A/S service for 1year |
| Why to cooperate with Phillaya |
ØPrice -competitive price (we are manufacturer ourselves)
ØQuality -reliable with guarantee period of 1year long (we have over 15 years' manufacturing experience)
ØDelivery -timely for sure (experienced engineer and workers under efficient management, with advanced equipment and technology)
ØService -prompt reply, efficient communication by phone/email/app online. Small order can be accepted. life-long After-sales, workable solutions to your request are available all the time! |
Qingdao Phillaya Internatio
nal Trading Co., Ltd. is acomphensive corporation majored in the Technology R& D, im
port &Export of kingds of semi trailers like co
ntainer semi trailer, flatbed semi trailer, side wall semi trailer, stake/fence semi trailer, van type semi trailer, lowbed semi trailer & kinds of draw bar trailer like flatbed drawbar trailer, dump drawbar trailer, side wall drawbar trailer &kinds of tank semi trailers like fuel tank semi trailer, LPG semi trailer, chemical liquid tank semi trailer, water/milk tank semi trailer, bulk cement semi trailer etc. of which tank bodys are made of carbon steel, aluminum alloy, or stainless steel.
Trailer parts such as landing gear, axle, suspension, chassis etc are all available here!
We, as the manufacturer, sincerely look forward to your enquiry and visit. Our co
ncept is to promise you better quality at competetive prices with best service all the time.
