Item | Description |
| Passenger Capacity | 2 |
Range (loaded) (km)* | Up to 42 |
| Max.Speed (km/h) | Up to 55 |
| Min.Turning radius (m) | 5.3 |
| Max.Climbing ability(loaded) | Up to 20% |
| Max.Movement after brake at speed of 20km/h | N/A |
| Max.Loading weight (kgs) | 1500 |
| Charging time (hour) | 8-10 |
| Battery lifespan (cycles) | 750 |
Item | Description |
| Overall dimensions (mm) | 4350x1500x2300 (LxWxH) |
| Rear cargo bed dimensions (mm) | 3000x1500x1400 (LxWxH) |
| Min.Ground clearance (mm) | 150 |
| Wheelbase (mm) | 2600 |
| Front wheel tread (mm) | 1280 |
| Rear wheel tread (mm) | 1220 |
Item | Description |
| frame &Chassis | Welded steel framework with sand blasting and painting |
| Cabin | Aluminum frame with FRP cover sheet and glass window |
| Front windshield | Laminated glass with wiper |
| Seat | Reborn sponge with artificial leather, highback |
| Floor | Skidproof leather |
| Rear box | Aluminum material, with side rolling door, with PVC water tank (1.3T) |
| Battery sliding system | Steel frame with sliding wheel |
| Beverage holders | 1 cups holders |
| Side rear view mirror | 2pcs, manual adjustable |
Item | Description |
| Lights | 12V, headlight (H/L beam), front turning light, Rear taillight (brake light and rear turing light) |
Horn | Electric horn, 12V |
| Reverse buzzer | Electric, 12V |
| Combination switch | Switch for headlight, turning light, wiper and horn |
| DC/DC converter | 72V/12V |
Warning light on the top | With siren |
| Audio system | Radio with MP3 receiver, with two waterproof speaker |
| Digital Meter | With Current meter, voltometer, speedometer and various indicators |
Item | Description |
| Steering System | Recirculating ball-type steering gear |
Brake System | 4-wheel hydraulic drum brake with hand park brake, with vacuum booster |
| Accelerator | Resistance type, stepless speed change |
| Front suspension | Non-independent suspension, cylinder hydraulic vibration absorber and leaf spring |
| Rear suspension | Integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
| Transmission system | Clutch, 5F+1R gear box, transmission shaft |
| Wheel &Tyre | 175R13C tubeless tire, 4J*13 steel rim |
