Our main products include full series products of CNHTC(HOWO,STR,Golden Prince,etc.), including dump truck, tractor truck, co
ncrete mier truck, sprinkler truck, water/Oil tank truck, truck mounted crane, co
ncrete pump truck.etc, and spare parts for them.
Product Des
criptio
nBasic technical da
ta:
| Basic Information | | |
| Vehicle name | Water fire truck | Chassis | ZZ1256M4646F |
| Outline size(L×W×H)(mm) | 9875×2490×3490 | Cargo inline size(L×W×H)(mm) | / |
| Rating mass(kg) | 15000 | Empty mass(Kg) | 13050 |
| Full mass(kg) | 28050 | Emission standard | Euro 2 |
| Engine Information | | |
| Model | WD615.62 | Type | Water cooling in-line six-cylinder turbocharged diesel engine |
| Power/displacement(KW/ML) | 193/9726 | Manufacture | Weichai Power Co., Ltd. |
| Chassis Information | | |
| Wheelbase(mm) | 5500 | Axle load(kg) F/R | Front :7000/Rear :25000 |
| Tire | 11.00-20,11.00R20 | Max speed (km/h) | 85 |
| Front overhang(mm) | 1560 | Rear overhang(mm) | 2520 |
| Front track(mm) | 1939 | Rear track(mm) | 1800 |
| Approach angel(°) | 15 | Departure angle(°) | 12 |
| Steering | Power steering | Brake | Air brake |
| Cabin | Straight head 2 rows 4 doors | |
| Special function | | |
| Tank capacity(L) | Water tank:10000LFoam tank:2000L | |
| Fire monitor | ModelPL48-64D dual-use monitor Water Range≥60m/1.0MPa Foam range ≥50m/1.0MPa |
| Fire pump | ModelCB10/60Flow60L/S Pressure1.0MPa |
