Item | Description |
| Controller | Curtis controller, 400A, imported from USA directly |
| Motor | Rated power 6.3KW (8.6HP)DC motor,7.5KW (10.2HP)AC motor Chinese brand |
Battery | Trojan battery, 12pcs T105+, imported from USA directly |
| Charger | 72V transfered smart charger, output 110V-240V,50-60HZ,out 72V/25A |
Item | Description |
| Passenger Capacity | 2 |
Range (loaded) (km)* | Up to 42 |
| Max.Speed (km/h) | Up to 55 |
| Min.Turning radius (m) | 5.3 |
| Max.Climbing ability(loaded) | Up to 20% |
| Max.Movement after brake at speed of 20km/h | N/A |
| Max.Loading weight (kgs) | 1500 |
| Charging time (hour) | 8-10 |
| Battery lifespan (cycles) | 750 |
Item | Description |
| Overall dimensions (mm) | 4350x1500x2300 (LxWxH) |
| Rear cargo bed dimensions (mm) | 3000x1500x1400 (LxWxH) |
| Min.Ground clearance (mm) | 150 |
| Wheelbase (mm) | 2600 |
| Front wheel tread (mm) | 1280 |
| Rear wheel tread (mm) | 1220 |
Item | Description |
| frame &Chassis | Welded steel framework with sand blasting and painting |
| Cabin | Aluminum frame with FRP cover sheet and glass window |
| Front windshield | Laminated glass with wiper |
| Seat | Reborn sponge with artificial leather, highback |
| Floor | Skidproof leather |
| Rear box | Aluminum material, with side rolling door, with PVC water tank (1.3T) |
| Battery sliding system | Steel frame with sliding wheel |
| Beverage holders | 1 cups holders |
| Side rear view mirror | 2pcs, manual adjustable |
Item | Description |
| Lights | 12V, headlight (H/L beam), front turning light, Rear taillight (brake light and rear turing light) |
Horn | Electric horn, 12V |
| Reverse buzzer | Electric, 12V |
| Combination switch | Switch for headlight, turning light, wiper and horn |
| DC/DC converter | 72V/12V |
Warning light on the top | With siren |
| Audio system | Radio with MP3 receiver, with two waterproof speaker |
| Digital Meter | With Current meter, voltometer, speedometer and various indicators |
Item | Description |
| Steering System | Recirculating ball-type steering gear |
Brake System | 4-wheel hydraulic drum brake with hand park brake, with vacuum booster |
| Accelerator | Resistance type, stepless speed change |
| Front suspension | Non-independent suspension, cylinder hydraulic vibration absorber and leaf spring |
| Rear suspension | Integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
| Transmission system | Clutch, 5F+1R gear box, transmission shaft |
| Wheel &Tyre | 175R13C tubeless tire, 4J*13 steel rim |
Item | Option description | Item | Option description |
| 1 | Rear steel bumper | 20 | Crowbar |
| 2 | Inner rear view mirror | 21 | Flashlights |
| 3 | Battery watering pipe | 22 | Life line |
| 4 | Water pump (handle) | 23 | Air mask |
| 5 | 3-point seatbelt | 24 | Firefighter clothing |
| 6 | Diesel heater for defrosting | 25 | Helmet with lighting |
| 7 | Electric power system | 26 | Fire gloves |
| 8 | Fire fighting kits | 27 | Fire boots |
| 9 | Fire foam | 28 | Safety Belt |
| 10 | Fire hose bracket | 29 | Fire hatchet |
| 11 | 65 fire hose | 30 | Fire blanket |
| 12 | Stream fire water gun | 31 | Taper barrel |
| 13 | Spray fire water gun | 32 | Separate belt |
| 14 | 65 gated Wye Valve | 33 | Danger caution plate |
| 15 | Fire hydrant wrench | 34 | Breathing apparatus |
| 16 | Hose ramp | 35 | Powder fire extinguisher |
| 17 | Fire pliers | 36 | Fire Axe |
| 18 | Hammer | 37 | Semicircular fire barrel |
| 19 | Fire spade | 38 |
