Bicycle Parts Ultrasonic Cleaner with Filter System, Ultrasound Bicycle Parts Cleaning Machine

Bicycle parts ultrasonic cleaner with filter, ultrasound cleaning machine with filter system


JTS-1048
Specification details:
Tank's total capacity: 168L
Tank's material: SUS304 / SUS316L
In-tank surface finishing: Hard-Cr Plating Treatment ( 20+ microns )
Housing's material: Stainless steel
Ultrasonic frequency: 28kHz / 40kHz
Ultrasonic transducer: 48
Ultrasonic output power (MAX. ): 2400W
Electronic generator: KG1200
Heater's (hot plate) power: 4.5kW
Cleaning tank's power requirement: AC 220V / 240V, 1, 25AMP
Generator's power requirement: AC 220V / 240V, 1, 13AMP

What is an "ultrasonic"?
Under ultrasonic is commonly understood sound waves whose frequency is above the threshold of human hearing (in the range of 16 kHz - 1 GHz). In addition, you can generate ultrasound with much higher energy, ie, much "louder" than the audible sound. In the use of ultrasonic technology distinguish the weak signal (test materials, medical supplies, diagnostics) and high-intensity ultrasonic, such as ultrasonic for cleaning, ultrasonic welding.
Applied to liquid media ultrasonic has found application in the so-called effect of "ultrasonic cavitation. " This effect is used as a basis in the ultrasonic cleaning device

Features:
Adjustable ultrasonic power
Original BLT type transducer
SUS 304/316L stainless steel tank
Adaptable for continuous operation
Adjustable thermo controller
Adjustable ultrasonic power
With separate control ultrasonic electronic generator
Sweep mode control available
Boost mode& oil skimmer upon clients requirement
Pressure pump and filter system are optional

Tank size is custom made.
MOQ: 1PCS
1 year warranty


Wide application:
· Diesel injection pumps
· metal parts prior to powder coating
· Electrical components
· Make-up cases
· Printer heads and toner cartridges
· Computer keyboards and mice
· Mobile phones
· Removal of dirt from motorcycle radiators
· Vehicle differentials
· Removal of metal swarf
· Milking parlour equipment
· Golf clubs & grips
· Ceramic pipes
· Horse bits & stirrups
· Carburettors
· Fuel injectors
· Guns and gun components
· Tattoo needles
· Surgical equipment
· Treasure
· Golf balls
· Motorcycle engine crank cases
· Engine cylinder heads
· Turbochargers
· Dentures
· Bicycle derailleurs
· Heat exchangers for combination boilers
· Engine camshaft rocker covers
· Horse brasses
· Knives, bayonets and other militaria

Model: Skymen™		JTS-1012	JTS-1018	JTS-1024	JTS-1030	JTS-1036	JTS-1072
TANK'S WORKING DIMENSION (mm)	L1	355	406	500	500	500	1000
	W1	305	305	355	406	460	600
	H1	355	460	500	500	550	600
OVERALL DIMENSION (mm)	L2	535	586	680	710	710	1210
	W2	485	485	535	586	640	780
	H2	750	680	720	720	770	720
TANK'S TOTAL CAPACITY		38L	56L	88L	101L	126L	360L
TANK'S MATERIAL		SUS304/SUS316L
IN-TANK SURFACE FINISHING		Hard-Cr Plating Treatment ( 20+ microns )
HOUSING'S MATERIAL		SUS 304/SUS316L
ULTRASonIC FREQUENCY*		28kHz / 40kHz
ULTRASonIC TRANSDUCER		12	18	24	30	36	72
ULTRASonIC OUTPUT POWER (MAX.)		600W	900W	1200W	1500W	1800W	3600W
ELECTRonIC GENERATOR		KG600	KG900	KG1200	KG1500	KG1800	KG3600
		Build-in	Separate
HEATER'S (HOT PLATE) POWER		1.5kW	3kW			4.5kW		9KW
CLEANING TANK'S POWER REQUIREMENT		AC 220V / 240V, 1, 15AMP				AC 220V / 240V, 1, 25AMP
GENERATOR'S POWER REQUIREMENT		----		AC 220V / 240V, 1, 13AMP
NEW PRODUCT 68kHz / 80kHz / 120kHz are also available
