Bicycle Parts Steel Balls Stainless Steel Ball

Basic information

AISI Number	AISI1008~AISI1018,AISI1045,AISI1065~AISI1086
Size	1.0mm----80mm
Grade	G5----G1000

Chemical Composition

Item	C%	Si%	Mn%	P%	S%	Density	Hardness
AISI 1010	0.08~0.13	0.30Max	0.50Max	0.07Max	0.06Max	7.861g/cm3	HRC 55-63
AISI 1015	0.13~0.18	0.10~0.30	0.30~0.60	0.04Max	*********
AISI 1045	0.43~0.50	0.10~0.30	0.60~0.90	0.04Max	0.05Max
AISI 1086	0.83~0.88	0.10~0.30	0.30~0.70	0.04Max	0.04Max

Material

Type	carbon steel ball	chrome steel ball	stainless steel ball
Model	AISI1008-AISI1086	100Cr6, AISI52100, GCR15, chrome steel	AISI304,316,420,440
Diameter	1mm-2"	1mm-2"	1mm-50mm
Grade	10-2000	10-2000	10-200

Main Products

Item	Name	Material
1	Stainless Steel Ball	AISI304/304L/316/316L/420/420C/440C
2	Chrome Steel Ball	AISI52100
3	Carbon Steel Ball	AISI1010/1015/1086

Steel Ball Metric and Inch Size

Material	52100 chrome steel
	1010 1015 1045 1085 1086 carbon steel
	304 316/L 420C 440/C stainless steel
	AL.5052 aluminum
	H62/65 brass
	T2 copper
Metric Size (mm)	0.4, 0.5, 0.68, 0.7, 0.8, 1, 1.2, 1.3, 1.45, 1.5, 1.75, 2, 2.5, 3, 3.5, 4, 4.5, 5, 6, 6.5, 8, 8.5, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 23, 24, 25, 25.4, 28, 30, 35, 40, 45, 50.8, 60, 76.2, 101.6, 150, 180
Inch Size (inch)	1/32, 3/64, 1/16, 5/64, 3/32, 1/8, 9/64, 5/32, 11/64, 3/16, 13/64, 7/32, 15/64, 1/4, 17/64, 9/32, 5/16, 11/32, 3/8, 13/32, 7/16, 29/64, 15/32, 31/64, 1/2, 17/32, 9/16, 19/32, 5/8, 21/32, 11/16, 23/32, 3/4, 25/32, 13/16, 27/32, 7/8, 29/32, 15/16, 31/32, 1, 1-1/16, 1-1/32, 1-1/8, 1-3/16, 1-1/4, 1-5/6, 1-3/8, 1-7/16, 1-1/2, 1-9/16, 1-5/8, 1-3/4, 1-7/8, 2, 2-1/4, 2-1/2, 2-3/4, 3, 3-1/4, 3-1/2, 3-3/4, 4, 5, 6, 7
Conversion	1inch=25.4mm, 1mm=1000um
Grade	G10 G16 G20 G28 G40 G60 G100 G200 G500 G1000
Precision	G10:0.25μm G16:0.4μm G20:.5μm G28:0.7μm G40:1μm G60:1.5μm G100:2.5μm G200:5μm G500:13μm G1000:25μm
OEM	Yes. (The sizes can be customized)

1.Application:
anti-friction bearings, steering columns, casters, conveyors and trolleys, roller skates, toys, and drawer slides.

2. Material Characteristics:
High hardness, and excellent wear resistance. Manufactured from the highest quality carbon steel.

Hardness
Case-hardened to Rockwell C - 60 (measured on parallel flats) to provide strength and long life.

3. Carbon Depths
Steel balls are hardened to these case depths.

aisi1086 high Carbon Steel Ball	aisi1010/1015 low Carbon Steel Ball
1. through hardened to HRC 60 min	1. case hardened
2. take higher loads than low carbon steel	2. soft core
3. provide longer life than low carbon steel	3. price saved compared to high carbon steel
4. more cheaper than chrome steel	4. resistance to shock loads, surface water,
5. used by cycle industry	5.used by castors, conveyors,

Application
Bicycle, bearing, pcision equipments, automobile, toys, furniture...

Chemical Components

AISI Number	C%	Si%	Mn%	Ci%	S%	P%	Hardness
AISI304	max0.07	max1.0	max2.0	17-19	max0.07	max0.045	HRC54min
AISI316	max0.07	max1.0	max2.0	17-19	max0.07	max0.045	HRC55min
AISI420	0.07-0.25	max1.0	max1.0	12-14	max0.04	max0.045	HRC58min
AISI440	0.95-1.2	max1.0	max1.0	16-18	max0.04	max0.045	HRC60min
AISI1008	max0.1	max0.3	max0.5	-	max0.6	max0.7	HRC55min
AISI1010	0.08-0.13	max0.3	max0.5	-	max0.6	max0.7	HRC55min
AISI1015	0.13-0.18	max0.3	max0.6	-	max0.6	max0.7	HRC58min
AISI1045	0.43-0.50	max0.3	max0.9	-	max0.6	max0.4	HRC60min
AISI1086	0.83-0.88	max0.3	max0.7	-	max0.6	max0.4	HRC60min
AISI52100	0.9-0.15	0.15-0.35	0.15-0.45	1.35-1.65	max0.03	-	HRC60min

Packing
1-6. Usual package
7. Packed as customers' required

Packing &Shipping:


Quality certificate
ISO9001 TUV


FAQ

1.Whatkindofsteelballscansupply ?

Material	Carbon,Chrome,Stainless
Sizerange	0.8mm-150mm
Grade	G10-1000
Packing	Standardorascustomerrequired
Delivery	Stockwithinashorttimeor35days

2.Some other question?

Q1.-- If 'I' want small quantity and fast delivery. Which way of shipping is advised?

A1.--By expss.

Q2.-- How many quantity will be packed in one carton or one pallet?
A2.--20 to 25kg per carton,1 ton per wooden pallet.

Q3.-- What's the lead time?
A3.--If in stocks,2-5days;or ,it will take 20-35days,depend on the quantity.

Q4. --Which kind of payment will be accepted?

A4. --T/T, West Union, L/C, ...



Welcome to contact us!
