High Quality Low Price Truck Front Axle Main The Bhutan Market

about product

OBT axle Features:
1). Special heat-treated, low-alloy steel axle beam, offers more stability, greater capacity and lighter weight.

2). Forged camshafts with hardened wear surface for the axle.

3). Solid inserted spindle and bearing journals laser heat treated, provide superior fatigue capability.

4). High performance pmium non-asbestos brake linings, extend service life.

5). Easy for ABS installation.


Semi Trailer Axle Specification:

GermanAxle
Model	105km /H Max. Load (kg)	"S"cam Brake Series φ× Width mm	Track TR mm	GM mm	Axle Beam mm	Spring Seat LM mm	WheelFixing			Total Length LP mm	Bear ing	Weight (kg)	Recomm ended Wheel
							Stud mm	P.C.D mm	φH mm
OBT 180	9000	S420 ×180	2040	622	Ο127	980	10-M22× 1.5 ISO	335	281	∽2146	33213 33118	∽364	7.50V-20
OBT 181	12000	S420 ×200	2040	622	Ο127	1180	10-M22× 1.5 ISO	335	281	∽2356	33213 3118	∽375	7.50V-20
OBT 182	12000	S420 ×180	1840	420	◊150	980	10-M22× 1.5 ISO	335	281	∽2156	33213 33118	∽372	7.50V-20
OBT 183	12000	S420 ×200	1840	354	◊150	900	10-M22× 1.5 ISO	335	281	∽2156	33213 33118	∽96	7.50V-20
OBT 184	14000	S420 ×180	1840	422	◊150	980	10-M22× 1.5 ISO	335	281	∽2188	33215 32219	∽402	8.0V-20
OBT 185	14000	S420 ×200	1840	354	◊150	980	10-M22× 1.5 ISO	335	281	∽2188	33215 32219	∽416	8.0V-20
OBT 186	14000	S420 ×220	1840	354	◊150	980	10-M22× 1.5 ISO	335	281	∽2188	33215 32219	∽430	8.0V-20
OBT 187	16000	S420 ×200	1850	356	◊150	900	10-M22× 1.5 ISO	335	281	∽2242	32314 32222	∽468	8.0V-20
OBT 188	16000	S420 ×220	1850	376	◊150	980	10-M22× 1.5 ISO	335	281	∽2242	32314 32222	∽474	8.0V-20
OBT 189	18000	S420 ×200	1850	356	◊150	900	10-M22× 1.5 ISO	335	281	∽2242	32314 32222	∽478	8.0V-20
OBT 190	18000	S420 ×220	1850	376	◊150	980	10-M22× 1.5 ISO	335	281	∽2242	32314 32222	∽484	8.0V-20

Our company

about CHENNUO
Jinan CHENNUO auto parts trade co., LTD.is located in the beautiful spring city - jinan, the company's products includes: Shantou DE card bridge, new steyr cab, D7B bridge, Shantou deka C7H whole vehicle, new steyr D7B whole car parts; Professional focus is the goal we have pursued;continuous innovation, constantly creating value for the new and old customers is our long-term vision.Our company has established long-term cooperative partnership with more than ten provinces and cities in China.We will continue to take the market as the orientation, update the concept as the pmise, enhance the core competitiveness of the enterprise, rapidly improve the enterprise's overall efficiency and innovation ability, make it a first-class modern enterprise.



Other products
The main products
Dump Truck;Tractor Truck;Container chassis semi-trailer series;Cargo semi-trailer series;Tipper semi-trailer series;Low bed trailer series;Concrete mixer series;spare parts,etc.





One-stop Service:

1. Professional Production Team:
More than 300 Experinced workers, provide clients high assembling for fast quality delivery.

2.Customize:
Professional design team provide suitable programs and customized, support local adaptive trailer.

3. 7*24h Service
7*24h service provide professional fast response.

4. Parts Support:
Abundant parts supply provide lasting support for worldwide clients.

5. DDP Logistic Transport:
Deliver to client anywhere in the worldby best logistic supplier.
