45m3 Dump Trailer 3 Axle Tipper Trailer Truck for Coal
Advantage for this3 Axles Tipper Trailer Tractor Dump Trailer
Lifting efficient Redundant force when driving
>>>Main f
rame:high-strength steel as the main beam,Widening &heightening big section, encryption arranged cross-beams and wing supporter,fully enhance and ensure their anti-torsion, anti-seismic, anti-bump capacity to meet the load requirements.
>>>Subf
rame:buckle the high strength steel (16Mn) into a box-shaped,fully and effectively to ensure its strength;make the cylinder and lower twist node of the pulling-arm into one-body to avoid bias,widening rear rollover point, can greatly improve the stability, safety and reliability of the whole vehicle running and lifting.
>>>Carriage structure:widening the carriage plate post,thickening carriage,good anti-swelling properties;Variety of the carriage plate to meet the transporting the sand-stone and coal etc. users of different cargoes; the rear carriage opening and closing automatically, unloading safely and reliably.
>>>Lifting Type: different lifting types for the different cargoes,there is the Mallely style rear unloading, the front-placing top rear-unloading, Side-dumping etc. various type for users to choose.
>>>Features for the Mallely style rear unloading: Good transverse stiffness,sleek and smooth lifting rotation,little lifting force coefficient,save labour, good oil pssure properties,long working life;enhanced trolley;using the company's patented product with the whole steel casting as the reinforced triangle arm.
>>>Features for the front-placing top rear unloading: simple structure, easy arrangement, the cylinder force coefficient is small;smaller systems weight;better impact resistance of the system; compact structure, high lifting efficiency.
>>>Features for the dropside type dump truck: suitable for dump vehicles with a lo
nger carriage length, low gravity center, good stability;with a unique oil circuit design, stable performance, easy to operate; discharging along the lo
ngitudinal direction,side doors on the side of dumping can be fully opened to shorten the discharging time, high efficiency;the unloaded cargoes scattered into a long strip along the side of the vehicle, and fitted with self-rescue cylinder with patented structure, effectively solve the problems that the wheels buried by the cargoes cannot walking after unloading cargoes; can be composed to be side-unloading train together with dump full trailer,effectively improving transport efficiency.
Product Des
cription:
| TrailerModel | 3AxleTipperSemiTrailer |
| ModelNumber | JSX9402DT |
| OverallDimension | 10000mm*2500mm*3500mm |
| (L*W*H)(mm) |
| InnerDimension | 8700mm*2360mm*1350mm |
| Axle | FUSAI13TONAxle |
| AxleNumber | Three |
| Lifting | HYVAhydraulicliftingsystem,liftingweight:55-90Tons |
| Track | 1840/1840/1840 |
| Suspensionsystem | Mechanicalsuspension,Threeaxisseriesbalancedsteelplatespringsuspension |
| SuspendSize(mm) | 1760 |
| SteelSpring | 10/10/10leafspringsuspension |
| CurbWeight(kg) | 8500 |
| LoadingWeight(kg) | 60000 |
| Thickness | bottom:8mm,side:6mm |
| TractionPin | 2'or3.5' |
| TireTypeandquantity | 1200R22.512pcs |
| FrontFittingRadius(mm) | 1760 |
| LandingGear | Zhenhuabrand28ton |
More types of theTipper Trailer Tractor Dump Trailer for your options:| Maintechnicalparameter | JSX9310ZZX | JSX3302CQ | JSX3250CA |
| Detailedinstructions | 21.2tonsdumpsemitrailer | Frontdumpsemitrailer | Sidedumpsemitrailer |
| G.W./kgs | 31,000 | 30,160 | 24,985 |
| TareWeight/kgs | 9,800 | 15,030 | 10,790 |
| Ratedload/kgs | 21200 | 15000 | 14000 |
| OverallSize(L*W*H/mm) | 13000*2500*3000/2900 | 10530/10380*2500*3550/3250 | 10400/9740*2500*3290 |
| Sizeoftheinsidebox(L*W*H/mm) | 12740*2260/2300*600/500 | 7700/7200*2270/2300*1500/1400/1200 | 7500/7200*2270/2300*1000 |
| Axlebase/mm | 6830+1310+1310 | / | / |
| TireSize | 11.00R20;12.00-20 | 11.00R20;11.00-20 | 11.00R20;11.00-20 |
| Wheelbase/mm | 1,840 | / | / |
| Leafspring/pcs | 8,10,12 | / | / |
| Approach/departureangle | 13/13.5 | 18/36 | /30 |
| Front/rearsuspension(mm) | 1100/2450;1400/2150 | 1510/2270,2120 | 1255/2710;1255/2410 |
| Saddlebearingcapacity/kgs | 9,650 | / | / |
| Model | Type | Payload/kgs | G.W. | TareWeight/kgs | OverallSize/L*W*H(mm) | Interiordimension/L*W*H(mm) | Axlespace/mm | Tyre | Remark |
| JSX9400ZZX | 3axlesReardumpsemitrailer | 31500 | 40000 | 8500 | 10850/10275*2500*3900 | 10050/9525*2300*600 | 5750+1310+1310;5250+1310+1310 | 11.00R2012R22.511R22.5 | |
| JSX9401ZZXDY | 3axlesSidedumpsemitrailer | 31500 | 40000 | 8500 | 13000*2500*3150 | 12750*2300*600 | 6830+1310+1310 | 11.00-2011.00R2012R22.5 | |
Detailed photos for Tipper Trailer Tractor Dump Trailer
Whyus???
1- Since 1987, With almost 30years'experience;
2-TwoYearsGuaranteeforallthethebeamoftrailers;
3-Reliability,SafetyandEconomicTransportsolutions;
4-OEM or ODM excellent service for you;
5-Strictqualitycontrol,out-standingqualityassurance;
6-StockTrailersandimmediatedelivery;
7-After-saleserviceavailable,Emailwillbereplied within8hours;
8-We fully understand where the supplier is in the market and where the buyer is in the market,and then we will proceed conscientiously.
Guarrantee for the parts of the Tipper Trailer Tractor Dump Trailer:| ITEMNAME | WARRANTY | ITEMNAME | WARRANTY |
| MAINframe | frame | 1YEAR | RUNNINGGEAR | AXLE | 6MONTHS |
| SUSPENSION | 6MONTHS | AXLEBEARING | 3MONTHS |
| KINGPIN | 1YEAR | WHEELHUB | 3MONTHS |
| BALANCEARM | 3MONTHS | TIRE | 6MONTHS |
| ITEMNAME | WARRANTY | ITEMNAME | WARRANTY |
| BRAKINGDEVICE | BRAKEDRUM | 3MONTHS | SUPPORTDEVICE | LANDINGGEAR | 6MONTHS |
| BRKECHAMBER | 3MONTHS | SPAREWHEELCARRIER | 6MONTHS |
| AIRRESERVOIR | 6MONTHS |
| ITEMNAME | WARRANTY |
| OTHERS | LEAFSPRING | 3MONTHS |
| BRAKECHAMBERDIAPHRAGM | 3MONTHS |
| EMERGENCYRELAYVALVE | 3MONTHS |
| BRAKESHOE | 3MONTHS |
| RELAYVALVE | 3MONTHS |
OurAdvantage
1>>>Withwellexperiencedsemitrailerproductioncompanytoofferhighqualityandcompetitivepricessemitrailertoourworldwidevaluablecustomers.
2>>>Anprofessionalteamwhichisexperiencedwithinternationalmarketandhasstrongtechnicalcapabilitytocustomizedcosteffective,because we have more than 60 Designer and engineers as our solid backing.Among them,our technical adviser has more than 40years'experience in the trailer field.
3>>>Sellwellintheinternationalmarkets,suchasAfricanmarket(Sudan,Angola,Zimbabwe,Liberia,Djibouti,Congo,Kenya,Ghanaect.),MiddleEast,SouthAsiaandSouth-Americamarketetc..
4>>>Two YearsGuaranteeforallthethebeamoftrailers,timelyshipment;
5>>>Dealing is not only buying or selling,but also the good matching;Not only product but also excellent service;Therefore we will be at your service at any time even the midnight in our time.
6>>>Your order could be a priority in our company whenever your order is small/medium size order or your low price.
7>>>We would be always grateful whatever you would be a"big fish for a small company or a small potato for a big company".
QualityControl
1** ForEachtrailer,wemustdothetestingandinspectthequality;and we have more than 30 QC&QA people on the production process and the testing process and warehouse to gurantee the quality of the every details.
2**You wilget theinspection certificateaccordingtocustomerdemandforeverytrailerwhich given byanindependentthirdparty certificationcompany.
3** You will get theout-standing quality assurance
