| GVW25000kgDrivingType6x4 |
| Model | ZZ3257M3247W | ZZ3257M3647WZZ3257N3647A | ZZ3257M3847WZZ3257N3847A | ZZ3257M4147WZZ3257N4147W | ZZ3257M4347WZZ3257N4347A |
| Productcode | 325760032 | 325760036325760936 | 325760038325760938 | 325760041325760941 | 325760043325760943 |
| Engine(Hp) | 266/290 | 266/290336/371 | 266/290336/371 | 266/290336/371 | 266/290336/371 |
| Power(Kw) | 196/213 | 196/213247/273 | 196/213247/273 | 196/213247/273 | 196/213247/273 |
| CarriageInternalDimensions(mm) | 4800x2300x1200 | 5400x2300x1400 | 5600x2300x15005800x2300x1500 | 6000x2300x1500 | 6300x2300x1500 |
| Cubage(m3) | 13.3 | 17.4 | 19.4/20 | 20.7 | 21.8 |
| SteelthicknessOfCarriage(mm) | Floor:8/Side:6mm | Floor:8/Side:6mm | Floor:8/Side:6mm | Floor:8/Side:6mm | Floor:8/Side:6mm |
| HydraulicLiftofCarriage | MiddleLift | MiddleLift | Middle/FrontLift | FrontLift | FrontLift |
| Dimensions(mm) | 7545×2496×3170,3386 | 8145×2496×3170,3386 | 8545×2496×3170,3386 | 8845×2496×3170,3386 | 9245×2496×3170,3386 |
| Kerbweight(Kg) | 12020 | 12250 | 12270 | 12480 | 12490 |
| Cab | HW76 |
| Transmission | HW15710/HW19710 |
| FrontAxle | HF9 |
| Steering | ZF8098 |
| RearAxles | HC16 |
| Wheels&Tyres | 8.5/12.00R20 |
| Engine | Model | WD615.62 | WD615.87 | WD615.69 | WD615.47 |
| Horsepower | 266 | 290 | 336 | 371 |
| MaximumoutputKw/r/min | 196/2200 | 213/2200 | 247/2200 | 273/2200 |
| MaximumtorqueN.m/r/min | 1100/1100-1600 | 1160/1100-1600 | 1350/1300-1600 | 1460/1300-1600 |
| Type | 6-cylinderinline,4-stroke,water-cooled,turbo-charged&inter-cooled,directinjection |
| BorexStroke | 126x130mm |
| Valve | 2 |
| Displacement | 9.726L |
| MakeSINOTRUCK(CNHTC),EuroIIemissionstandard,Thermostatwith80ºCopeningbegin,Rigidfan |
| Option:Thermostatwith71ºCopeningbegin;siliconeoilfan;Cold-startwithelectric-inlet-airheatingSystem(180Ahbattery) |
| Cab | SINOTRUKHW76Lengthencab,singlebunk,newtypeseat,adjustablesteeringwheel,EUROnewtypeheating&ventilatingsystem,GermanVDOinstruments,safetybelts,exteriorsunvisor,stereoradio/cassetterecorder,leftdriving,airConditioner.Option:rightdriving;color |
| Clutch | SINOTRUKΦ430diaphragm-springclutch,hydraulicallyoperatingwithairassistance |
| Transmission | SINOTRUKHW15710orHW19710transmission,10forwardand2reverseRatio:14.2810.627.875.884.383.272.431.801.341.0013.91(R1)3.18(R2) |
| FrontAxle | SINOTRUKHF9FrontAxle,new9-tonfrontaxlesofequippedwithdrumbrakesOption:discbrake |
| Steering | GermanZF8098SteeringGearBox,hydraulicsteeringwithpowerassistance,Ratio:22.2-26.2 |
| RearAxles | HC16Heavyreductiondriveaxle,STRhub-reductionwithdifferentiallocksbetweenwheelsandaxles,enforcedSTRaxle,ratio:5.73;ThebasicconfigurationofHOWOseriesconstructionvehiclecanbeusedinsuchbadenvironmentas badroadcondition,heavyimpactandoverloading,whichisthebestchoiceforheavyconstructionvehiclecustomers. |
| BrakeSystem | Servicebrake:dualcircuitcompssedairbrakeParkingbrake(emergencybrake):springenergy,compssedairoperatingonrearwheelsAuxiliarybrake:engineexhaustvalvebrake |
| Wheels&Tyres | Rims:8.5-20,10hole-steel;Tyres:12.00-20diagonaltyrewith1SparetireOption:12.00R20radialtyre |
| Electrics | Operatingvoltage:24V,negativegroundedStarter:24V,7.5KwAlternator:3-phase,28V,1500WBatteries:2x12V,165AhCigar-lighter,horn,headlamps,foglights,brakelights,indicatorsandreverselightOption:2x180AhBatteries |
| OilTank | Squaretype-300LAluminumalloyfueltank |
| OtherOptional | VerticalMuffler;ABS;AutomaticBreakClearanceAdjustingArm;TravelingDataRecorder;metalPipeline;EngineProtectiveBoard |
| Deliverydate | Within45daysafterreceiptadvance |
| Weightinkg | Grossvehicleweight25000Frontaxleloadingcapacity9000Rearaxlesloadingcapacity2x16000 |
| Performance | Maximumdrvingspeed(km/h) 75Fuelconsumption(1/100km) 38 |
| Packing | NudePack.Thepackingofthecommodityshallbeinaccordancewiththeexportstandardpackingofthemanufacturer,besuitableforlongdistancetransportationofoceanandinland.TheSellershallbetakemeasuresagainstmoisture,shocksandrustaccordingtothespecialneedsofthecommodity. |
