| Model | ZZ5707V3840CJ | |
| Dimension(L×W×H)(mm) | 8600x3300x4340 | |
| Cargo dimension(mm) | 5500x3100x1800,, Rectangular compartment with the back door, matts plate type box | |
| Cargo thickness(mm) | 1210,16Mn Bottom12mm side 10mm,16Mn Material | |
| Lifting system | Front lifting system China brand180,100 gear pump,add two sides of the fence and defensive drill protection. | |
| Total Weight | 75000kg | |
| Curb weight(kg) | 23000kg | |
| Rated weight(kg) | 52000kg | |
| Wheel base(mm) | 3800+1500mm | |
| Front axle | HF12,12, HF12,drum brake | |
| Rear axle | AC26,26 AC26,Radio 8.51 | |
| Engine | Model | D12.42T2,420HP |
| (L) Displacement | 11.596/Diesel | |
Emission | EURO 2 | |
| Transmission | HW21712()+HW70 HW21712,12F&2R,double oil -pump,HW70 PTO Flange Type | |
| Tank dimension(L) | 500 | |
| Driving steering | ZF8118, ZF8118,left driving | |
| frame | 10+10/380 | |
| Tire | 14.00-25 | |
