Detailed Description
Specifications
1. Dump truck
2. CCC&ISO certificate
3. Competitive price
Advantages for 6x4 SINOTRUK HOWO dump truck:
1. Heavy duty truck chassis
2. Reinforced body structure with proven telescopic tipping gear
3. Combination of ride comfort and power
4. Key pssure point reinforced cargo body
5. Robust powertrain can help you tackle any challange at the co
nstruction site
6. Stable and reliable under-body tipping device ensures low-gravity hoisting
SINOTRUK 6×4 HOWO DUMP TRUCK LHD DRIVE
| Cabin | ZZ3257M3847W |
| HW76 cab. Original luxury Volvo cab with two seats, A sleeper and an A/C. photo for your reference. |
| Vehicle Main Dimensions | L×W×H(mm) | 8545×2496×3386 |
| Wheel track(mm) | 1830 |
| Wheel base(front/rear) (mm) | 3825+1350 |
| Approach/Departure angle(°) | 19/23 |
| Weight in KGS | Tare Weight(kg) | 12400 |
| Loading Capacity(kg) | 40000 |
| Front axles loading capacity(kg) | 1×8000 |
| Rear axles loading capacity(kg) | 2×8500 |
| Max.Drinving Speed (km/h) | 80 |
| Engine | Brand | SINOTRUK |
| Model | WD615.87 |
| Type | 6-cylinder in-line with water cooling;
4-stroke direct injection;
turbo-charging and inter-cooling |
| Horse Power(HP) | 290HP(option:266hp/336hp/ 371hp) |
| Emission Standard | Euro II |
| Axle | HC16 design overall cast steel axle. |
| Gearbox | HW15710.10 block transmission, Ten Forward & Two reverse. |
| Clutch | Reinforced diaphragm spring clutch, diameter 430mm |
| Steering Gear | ZF8098,original made in German. Power steering, hydraulic steering with power assistance. |
| Fuel Tank(L) | 300L |
| Tire | Eleven units of 12.00-20 Nylon tires.(option:12.00R20) |
| Brakes | Service brake: dual circuit compssed air brake
Parking brake: spring energy, compssed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake |
| Dump Body |
| Thickness | Side | 4mm in high tensile strength steel Q345B |
| Front | 4mm in high tensile strength steel Q345B |
| Bottom | 8mm in high tensile strength steel Q345B |
| Dump Body Size | L×W×H | 5800mm×2300mm×1500mm |
| Tipping Hydraulics | Tipping Type | Front tipping type |
| Tipping System | Complete set of Local brand front tipping type hydraulics system |
