FAW Light Wrecker Tow Truck, 5 tons Flatbed Wrecker Tow Truck

FAW Light Wrecker Tow Truck, 5 tons Flatbed Wrecker Tow Truck

Company information:
We're one professional manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as dump truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.


We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.

Items		Unit	Value
Boom Structure	Rated towing weight	kg	8400
	Max. Lifting weight	kg	1500
	Max. Lifting weight of full extending boom	kg	800
	Effective length of boom	mm	1788
	Extension traveling of boom	mm	1200
	(/) Elevation of boom (upper/ lower)	°	7~-10
Platform Structure	Min. Elevation of full extending platform	°	11
	Max. Loading of platform	kg	3000
	(××) External dimension of platform (length×width×height)	mm	6150×2200×57
	Ground clearance of cage floor	mm	1157
	Max. Pulling power of winch	kg	4000
	Dia. Of steel cable	mm	10
	Length of steel cable	m	25
	Min. Speed of steel cable	m/min	4.5
Vehicle Parameters	External dimension	mm	9047×2280×2775
	Refitted by		Qingdao HETANCH Truck Co.Ltd
	Drive		4×2
	Axle base	mm	4800
	The whole weight of empty load	kg	5665
	Load of front axle of empty load	kg	2525
	Load of rear axle of empty load	kg	3140
	The whole weight of full load	kg	8495
	Load of front axle of full load	kg	2995
	Load of rear axle of full load	kg	5500
	(/) Wheel base (front/rear axle)	mm	1810/1740
	Front suspension	mm	1330
	Rear suspension	mm	2480
	Approach angle	º	18
	Departure angle	º	13
	Max. Speed	km/h	99
	Max. Grade ability	%	≥32
	Min. Turning diameter	m	≤19
	Min. Ground clearance	mm	215
	Engine model	-	CA4DF3-13E3/ CA6DF-18E3
	Engine emission	ml	4750
	Rated power	Hp/r/min	130/2500, 180/2500
	Max. Torque	n·m/r/min	430/1500
	Fuel type		Diesel
	Standard of emission		Euro II, III, IV, V
	Tire size		9.25R16(optional 9.00R20-16,10.00R20-16)
	Persons		3
Optional: Lifting crane	Crane brand		XCMG, or Other China brand
	Lifting Capacity	tons	2, 3 , 5 tons
	Crane model		SK2, SK2.5, SK3, SK5
	Boom type		Articulated type
	Maximum effective length	(mm)	1940
	maximum traction speed	Km/h	30
