ISO9001/CE/SGS High Effeciency Two Worms Slewing Drive

DE model is mainly used in the applications which need high strength and high output such as wind energy and construction equipments, its high strength,high output torque and excellent selflock performance provide excellent solutions in high load truck steering system and rotating system of welding equipments .

DE Model Slewing Drive Dimensions
Model		Ratio	External Dimensions				Mounting Holes Dimensions
			L1	L2	L3	H	D1	D2	n1	M1	n2	M2
14"		85:1	589.5	237.6	492	132	468	344	21	M16	24	M16
17"		102:1	674.5	280.4	577	132	553	429	16	M16	16	M16
21"		125:1	789.5	338.2	692	134	668	544	24	M20	24	M20
25"		150:1	914.5	401.0	817	134	793	669	24	M20	24	M20
DE Model Performance Parameters
Model	Rated Output Torque	Max Output Torque		TiltingTorque		Axial Load	Radial Load	Holding Torque	Efficiency	Precision	Self-locking	Weight
	N.m	N.m		N.m		kN	kN	N.m		degree	Yes	kg
14"	18000	27000		135000		680	230	88400	40%	≤0.050	Yes	70 kg
17"	27000	40500		203000		980	390	106080	40%	≤0.050	Yes	102kg
21"	48000	72000		271000		1600	640	130000	40%	≤0.050	Yes	153kg
25"	64500	96750		346000		2400	950	178000	40%	≤0.050	Yes	202kg

1. We can install different types of electrical or hydraulic motor based on customer's requirements
2. We can provide all the standard products or specially design based on customer's requirements
3. We can paint all kinds of color based on RAL code
4. We can use reasonable IP grade based on your application
5. Please contact us if you need detailed sales drawing
6. Above dimensions and parameters may be updated or adjusted, please refer to our sales drawings for detailed dimensions and parameters
