China Manufacturer Cement Cardan Shaft Coupling

SWC Cardan Shaft / Propeller Shaft / Drive Shaft / Universal Joint Shaft / Transmission Shaft

Product Description:

A Seris Cardan Shaft


A Seris Cardan Shaft
Parameter and Dimensionsof A Seris Cardan Shaft

Model	Mmax	A		B	C	E	F	G	M	S	I		n-H	Lz	La
A1-1	500	75	30°	42	38	5.5	2	16	52	83	62		6-6	430	30
A1-3	530	90	30°	47	36	6	4		48	83	75		6-8.5	430	30
A1.1-4	1100	100	25°	60	50	7	2	13	41	93	80	50	4-10.2	370	30
A1.1-5	2000	148	25°	95	86	11	2.5	31	78	130	120	40°	4-14.5	580	40
A2-1A	1300	120	20°	70	60	8	2.5	22	50	114	96	62	4-12	500	40
A2-2	1940	148	20°	95	86	11	2.5	31	62	139	20	40°	4-14.5	550	40
A2-4A	3900	205	20°	198		11	2	35	77	187	185		8-11	615	40
A2-5A	7800	205	20°	198		11	2	35	86	205	185		12-11	700	45
A2-6	12700	250	15°	240	180	18	4	24	94	235	220		8-14.3	770	45
A3-1T	25000	225	10°	135	30	18	7	9	125		196		6-19	1165	120
A3-1	25000	265	10°	160	30	20	7	9	116	265	230		6-21	1150	115
A3-2	50000	290	10°	168	32	30	7	9	150	290	250		10-23	1420	100
A3-3	35000	315	10°	190	32	35	7	9	160	310	280		10-23	1500	100
A3-4	40000	380	10°	220	32	30	8	9	175	354	340		10-23	1500	100
A3-5	60000	380	10°	220	40	30	8	15	175	354	340		10-23	1500	100
A3-6	80000	380	10°	220	40	30	8	15	185	380	340		10-23	NOT
A3-7	100000	380	10°	220	40	30	7	15	175	380	340		10-23	1590	100
A3-8	160000	400	10°	235	70	40	10	18	205	400	355		10-25	1650	100
A3-9	250000	450	10°	310	80	42	10	20	215	420	400			1640	100

Marks:
1, Mmax= The max work torque
2, Lz = Min length after compssion
3, La = Length compensation
4, Lz+La = The max work length
5, B = Schneider pcision
6, n = number of flange holes
7, The A3 series allows the middle without flange connection,use a fork and a welded pipe to weld directly
8, If you have other requirements (big flange, big compensation etc.), please contact our design department.
A3-9 The size and quantity of flange hole need to discuss together.
