Item No. |
Parameters |
|
Overall Dimension |
10590x2495x3350mm |
|
Driving Model |
Left hand drive |
|
Gross Vehicle Weight |
25000kg |
|
Curb Weight |
14000kg |
|
Payload |
10000kg(10Ton) |
|
Wheel base |
4600+1350mm |
|
Front/rear Tread |
2022/1830mm |
|
Approach/Departure Angle |
16/12degree |
|
Front Axle |
HF7,7000kg |
|
Rear Axle |
ST16,16000kgX2 |
|
Engine |
WD615.87,4-stroke direct injection,6-cylinder in-line with water cooling,turbo-charging and inner cooling |
|
Engine horsepower |
290HP EUROII |
|
Displacement |
9760mL (Diesel) |
|
Max Driving Speed |
95km/h |
|
Gearbox |
HW19710 |
|
Cabin |
Standard HW76 cabin,2~3 Passenger allowed,with Air Conditioner |
|
Tire |
12R22.5(11pieces) |
|
LPG tank |
|
|
Volume: |
20cbm |
|
Tank material: |
Q345R |
|
Tank diameter: |
2050mm |
|
Tank thickness: |
10mm |
|
End plate |
10mm |
|
Tank length: |
7644mm |
|
Gas phase |
DN50 |
|
Liquid Phase |
DN80 according to Niger market |
|
Filling gas |
Propane(LPG) |
|
Design Pressure: |
1.61Mpa |
|
Accessory |
|
|
LPG Pump |
1 pc |
|
LPG Volume Flow Meter |
1 pc |
|
Filling hose with filling nozzle |
15M |
|
Level Gauge |
Manual rotation type,at the rear of tank |
|
Safety Valve |
1,DN80 |
|
Tool and Valve Box |
1 |
|
Thermometer |
1 |
|
Pressure Gauge |
1 |
|
Level gauge |
Manual Rotation Type |
|
Emergency Valve |
1 |
|
Fender |
Steel |
|
Fire Extinguisher |
2 |
|
Exhaust shaft |
At the front of truck for safety |
ChengLi Special Automobile Co.,Ltd, appointed by the Ministry of Industry and Information Technology of China, is one of the biggest special truck manufacturer in China.
1.We maintain a long and interactive cooperation relationship with our chassis suppliers, such as DONGFENG, FAW, SINOTRUK, FORLAND and etc;
2.Capacity of production of more than 300 kinds of special trucks and semi-trailers, higher standard is always what we pursuit;
3.Exportation to more than 68 countries, such as Africa, South-east Asia, Australia and etc, reliability and good quality are our key points to gain our customers' reputation.
Our Service
1. Special Truck Manufacturing: Dump Truck, Sewage Suction Truck, LED Advertising Truck, Ice Cream Truck, Refrigerator Truck ...
2. Pressure Vessel Manufacturing: LPG,Liquid Ammonia,Dimethyl ether,Isobutane,Propylene
3. We will reply you for your inquiry in 24 hours.
4. After sending, we will track the products for you once every two days, until you get the products. When you receive the goods, test them, and give us a feedback.If you have any questions , contact with us, we will provide technique solutions for you.
FAQ
Q1: What is your terms of payment?
A: T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2. What is your terms of delivery?
A: FOB, CFR, CIF
Q3. How about your delivery time?
A: Generally, it will take about 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the customer’s requirements?
A: Yes, we can produce by your requirements or technical drawings.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
