Manual Type Trolley/ Plain Trolley for Hoist Equipment

Product Description:



Detailed Product Description

C32 Stainless Steel Rail Festoon System End Trolley

All components about the stainless C track will be stainless included the bearing and shaft.
The stainless C track will be specially used in Galvanizing mill, Corrosive and acidic Working condition.


Factory Price Heavy Duty Festoon System For Crane-C Track, C Track Festoon System for Crane, GalvanizedSteelConductorRailsWithBrassDowel,C Rail and Trolley, Stretched Wire Festoon System, Festoon Cable Trolley, Festoon Cable System.

Detailed Product Description
Festoon System can hold conductor cables and hoses (hydraulic and pneumatic applications) for delivering power & control to mobile equipment in a safe, efficient and maintenance free method.
The C-track system is one of the most versatile festooning techniques available. It is an all-purpose system suited for either indoor or outdoor use under a broad range of operating conditions in a mild environment condition.

Application
C-rail systems applications: crane manufacturing, hoist units, transport systems, special engineering, stacking systems, conveyor system, etc. C-rails are available in zinc-coated and stainless steel version (program 230 to 240). Special versions are available for explosion-proof areas.

Design features:
Compact arrangement, corrosion resistance and simple assembly are its essential features. Easy for transportation and installation

Technical Parameters

Type	C32*30*1.5	C40*40*2.0	C63*63*4.0	C30*28*1.5
Material	Stainless stell 304
Weight kg/m	1.19	2.00	5.98	1.03
Technical data
A	32	40	63	30
B	30	40	63	28
C	12	13	18	10
6	1.5	2.0	4.0	1.5
Spacing	Max. Cable Load
1.5m	89kg	188kg	503kg	70kg
2.0m	51kg	103kg	425kg	36 kg
2.5m	39kg	73kg	302kg	22kg
3.0m	23kg	49kg	195kg	-
4.0m	-	28kg	85kg	-
