| Specification | FD35 | |||||
| 1 | Characteristics | Fueltype | Diesel | |||
| 2 | Loadcapacity | kg | 3500 | |||
| 3 | Loadcenter | mm | 500 | |||
| 4 | Liftheight | mm | 3000 | |||
| 5 | Fullfreeliftheight | mm | 135 | |||
| 6 | Forkdimension | mm | 1070×125×50 | |||
| 7 | Masttiltingangle | Front/Rear | Deg. | 6/12 | ||
| 8 | Min.turningradius | mm | 2530 | |||
| 9 | Min.widthofrightanglestackingchannel | mm | 4335 | |||
| 10 | Min.widthofrightanglechannel | mm | 2235 | |||
| 11 | Groudclearance | mm | 120 | |||
| 12 | Overheadguardheight | mm | 2120 | |||
| 13 | Frontoverhang | mm | 498 | |||
| 14 | Performance | Max.travelspeed | Fullload | km/h | 19 | |
| 15 | Max.liftspeed | Fullload | mm/s | 460 | ||
| 16 | Max.tractionpower | Fullload | KN | 22 | ||
| 17 | Max.gradeability | % | 20 | |||
| Dimensions | Totallength | Withfork | mm | 3905 | ||
| 18 | Totallength | Withoutfork | mm | 2835 | ||
| 19 | Totalwidth | mm | 1230 | |||
| 20 | Mastextendedheight | mm | 4265 | |||
| 21 | Mastloweredheight | mm | 2040 | |||
| 22 | Chassis | Tyres | Front | 28x9-15-12PR | ||
| 23 | Rear | 6.50-10-10PR | ||||
| 24 | Wheelbase | mm | 1700 | |||
| 25 | Tread | Front/Rear | mm | 1000/970 | ||
| 26 | Serviceweight | Kg | 4500 | |||
| 27 | Drive | Battery | V/Ah | 12/100 | ||
| 28 | Motor | Model | ISUZU4JG2 | |||
| 29 | Ratedoutput | kw/r.p.m | 44.9/2450 | |||
| 30 | Ratedtorque | N.m/r.p.m | 184.7/2450 | |||
| 31 | Cylinders | 4 | ||||
| 32 | Displacement | L | 3.06 | |||
| 33 | Fueltankcapacity | L | 70 | |||
| 34 | Transmission | |||||
| 35 | Operatingpssure | Mpa | ||||
