Chinese Styer Wd415.24c Diesel Engine for Truck

Chinese styer WD415.24C diesel engine for truck


WD415 series marine diesel engine as the WD615 marine diesel engine's sister products, draw the most advanced diesel engine design concept in Europe, the key to strengthen the design of the basic parts, but also to further improve the reliability. In particular, the design of the frame type dual axis balance mechanism installed in the bottom plane of the crankcase, which completely solves the problem of the vibration of the four cylinder diesel engine, and the quality of the six cylinder diesel engine. Power range 58kW-158kW, speed range 1500-2100rpm.
Super power: the maximum power of up to 240 hp;
Superior performance, economical and practical: equipped with special fuel injection pump, main engine with parking electromagnet, auxiliary engine with electronic governor, in a wide power range and speed range is extremely low fuel consumption, minimum fuel consumption rate is lower than the 198g/KW.h.
Patent balance mechanism: completely solve the two - level reciprocating inertia force of the four cylinder engine, the whole balance mechanism is placed in the oil pan, and does not affect the overall size of the engine and the original structure of the engine, so that it is easy to arrange in the cabin.
Application scope is wide: the main driving force and the auxiliary power of a variety of ships are widely used.

Model	Order number	Intake mode	Rated power/speed kw/r/min	Overload power/speed kw/r/min	Dmensions L*W*H(mm)	Min.full load fuel consumption g/kw.h	Net weight(kg)	Adaptable gearbox type
WD415.24C	41524C01	Turbocharged intercooled	158/2100	174/2163	1610*830*1170	198	800	135,120C,MB242,MB270A,
	41524C02		148/1800	163/1858
	41524C03		135/1500	149/1545

Other model list

Model	Rated Power/ Speed (kW/r/min)	Peak Torque/Speed (N.m/r/min)	Emission Index
WD415.23 ENGINE	166/2200	880/1300-1600	EUROII
WD615.46 ENGINE	266/2200	1460/1400-1600	EUROII
WD615.340 ENGINE	294/2200	1600/1100-1600	EUROIII
WD615.338 ENGINE	276/2200	1500/1100-1600	EUROIII
WD615.327 ENGINE	198/2200	1150/1100-1600	EUROIII
WD615.50 ENGINE	201/2200	1110/1100-1600	EUROII
H615.68K02 ENGINE	225/2200	1250/1300-1400	EUROII
WD415.24 ENGINE	177/2200	950/1300-1600	EUROII
WD415.18 ENGINE	137/2200	710/1300-1600	EUROII
WD615.329 ENGINE	213/2200	1160/1100-1600	EUROIII
WD615.334 ENGINE	247/2200	1350/1100-1600	EUROIII
WD615.64 ENGINE	175/2200	1000/1300-1600	EUROI
WD415.21 ENGINE	155/2200	820/1300-1600	EUROII

Packaging & Shipping

Packaging Details	plywoond case
Delivery day	3 weeks

If you would like to get a good offer for Steyr marine engine, please feel free to contact us,
