FAW 4X2 Refrigerator Truck/Chill Truck
Quick deatail:
Axles: 2
Horsepower: 180 HP Standard: Euro III
Engine: CA6DF3Speed: 96 km/h
Van demension: 6640×2335×2400mm
Temperature: -18 °c
Contact: Ms.Beria Huang
Tel:+8615507234243
PARAMETER
| Description | Faw 4X2 Refrigerator Truck |
| Drive Model | 4X2 |
| Chassis | CA5160 |
| Vehicle Main Dimensions | Dimensions(L xW xH)mm | 9250*2550*3810 |
| Wheel base (mm) | 5300 |
| Overhang (front/rear) (mm) | 1400/2450 |
| Wheel track (front/rear) (mm) | 1800/1800 |
| Approach/Departure angle(°) | 18/10 |
| Weight in KGS | Curb Weight | 7570 |
| GVW. | 16000 |
| Max. driving speed(km/h) | 96 |
| Engine | Model | CA6DF3-18E3 |
| Type | 4-stroke direct injection ,6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Horse Power(HP) | 180HP |
| Emission standard | Euro III |
| Gearbox | 6 forwards &1 reverse |
| Clutch | Reinforced diaphragm clutch |
| Steering Gear | Power steering, hydraulic steering with power assistance |
| Fuel tank (L) | 180 |
| Tire | 9.00-20 16PR ,6 pcs+1 |
| Brakes | dual circuit compssed air brake |
| Van |
| Material | 1. Fiber steel double deck
2. with 8CM thickness polyurethane
3. Fiber steel/Stainless steel/Color plate can be choosen |
| Tipper Box Dimension | 6640*2335*2400mm |
| Thickness | 10CM |
| Temperature | -18ºC or -5ºC as your choice |
Truck refrigerator
| Unit model | F700 |
| Refrigerator Type | HUATAI |
| Applicable temperature (ºC) | 20ºC~+25ºC |
| Applicable volume(m3) | 27~37(-20ºC) |
| Cooling capacity | Environmental
temperature | 0ºC | 3300W |
| -18ºC | 3700W |
| Voltage (V) | 12V/24V |
| Current (A) | 37A/62A |
| compssor | Displacement (cc/r) | UPF170/TM16 (172cc/r) |
| condenser | Air flow (m3/h) | - |
| Fan type | - |
| number | - |
| evaporator | Air flow (m3/h) | - |
| Fan type | - |
| number | - |
| refrigerant | R404A 3.6~3.9Kg |
| Refrigerant charge amount(Kg) | |
| Defrost type | - |
| Dimensions(mm) | evaporator | 1700×644×230 |
| Condensing utensil | 1265×555×415 |
| Weight(KG) | evaporator | |
| Condensing utensil | |
| Remark | Optional to install for 380v store electric power |
THE PRICE IS AVAILABLE FOR 30 DAYS.
Our advantage:
· Competitive Price and Excellent Quality,
· More than 10 years' experience as amanufacturer,
· CCC, ISO, BV certification,
· Perfect after-sale service,
· Customized products available with us,
· Export covering More than 50 countries and regions,
· Annual production value topped 1500, 000, 000 RMB (240, 000, 000 US dollars) per year.
CLW Heavy Industry Co., Ltd is the branch company of Chengli Special Automobile Co., Ltd. Chengli Special Automobile Co., Ltd, as the professio
nal manufacturer in the special vehicle circle, has developed into the biggest professio
nal special vehicle manufacturer of central China starting from scratch since 2004.
Chengli Special Automobile Co., Ltd Factory Supply:
A. Special truck manufacturers in Suizhou city, HuBei province, China,
B. More than 300 kinds of special truck for your needing. Such as garbage truck, LPG truck, fuel truck, water truck, high platform truck, dump truck, co
ncrete mixer truck, truck mounted crane, chemical tank truck, fire fighting truck, bulk cement truck, flat bed trailers, low bed trailer, cargo trailer tipper trailer, fuel trailer, LPG trailer and more
C. Nearly 15 years experience in produce truck and truck parts field.
D. Export turnover has reached 25million dollars and our products have been sold to more than 50 countries, including Africa, Europe, Southeast Asia, Middle East, North Asia and so on.
Owing to our rich industrial experience, we are offering awide range of products to the customers, such as LPG tank, fuel tank, water truck, refrigerator truck, garbage truck and so on. We ensure to deliver those products at industry leading price range to meet the financial co
nstraints of our clients.
Our main products:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck
2. Water truck /Water Tank Truck /Water Sprinkler Truck/Water Tanker
3. Truck with crane /Truck mounted crane
4. Dump Truck /Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck /Fire Truck /Fire Vehicle
6. Co
ncrete Mixer Truck
7. Van truck /Blasting equipment transporter/ Refrigerated truck
8. Fecal suction truck /Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer (flat bed trailer /skeleton trailer /dump semi trailer /side wall trailer /low bed trailer /van co
ntainer trailer /warehouse trailer, etc. )
More information of LPG truck, LPG tank truck, liquid petrol gas tank truck, please feel free to co
ntact with MR Albert Du. We will customize the truck according to your requirement. Sincerely welcome you to visit our factory and provide your pcious suggestion for us!
