| Model | EG202AK | EG202AK02 | EG202AK03 |
| System | 48V/3KW AC | 36V/3KW Sepex | 48V/4KW Sepex |
| Key Components | | | |
| Battery | 6PCSxT875(145Ah@5hr rate) | 6PCSxT105(185Ah@5hr rate) | 6PCSxT875(145Ah@5hr rate) |
| Motor | 3KW Germany motor | 3KW ADC | 3.8KW Chinese motor |
| Controller | Zapi ACE0(280A@2minutes) | Curtis 1243 (300A@2minutes) | Curtis 1268 (400A@2minutes) |
| Performance | | | |
| Passenger capacity | 2 | 2 | 2 |
| Range (loaded) based on flat road at aspeed of 30km/h (km)* | >70 | >55 | >65 |
| Max.Speed @12.76:1 gear ratio | 32 | 21 | 32 |
| Max.Speed @10.26:1 gear ratio | -- | -- | 40 |
| Minimum turning radius (m) | 3 | 3 | 3 |
| Max.Climbing ability (loaded)@ 12.76:1 gear ratio | 25% | 25% | 25% |
| Max.Climbing ability (loaded)@ 10.26:1 gear ratio | -- | -- | 20% |
| Max.Movement after brake at speed of 20km/h | ≤4m | ≤4m | ≤4m |
| Max.Loading weight | 270kgs | 270kgs | 270kgs |
| Net weight | | | |
| Dimensions |
| Overall dimensions (mm) | 2410x1180x1800 |
| Min.Ground clearance (mm) | 120 |
| Wheelbase (mm) | 1680 |
| Front wheel tread (mm) | 1010 |
| Rear wheel tread (mm) | 1010 |
| Detailed Configurations:("S" stands for Standard configuration and "O" stands for Optional configuration) | |
| Body and frame | | | |
| frame | Aluminum alloy beam | | |
| Body | PP plastic front body +PP plastic rear body | |
| Roof | Plastic | | |
| Windshield | One-piece Organic glass | | |
| Windshield, hinged | | |
| Roof support | Aluminum, including front upright, rear upright, caddie handle | |
| 2point seat belt | | | |
| Large Seats: | | | |
| 1) backrest and cushion | Foamed cushion +formed vinyl(artificial leather ) | |
| 2) armrest | Plastic, black texture finish | | |
| 3) plastic seat bottom | | | |
| Backrest cover in wood finish | | | |
| Steeing wheel in wood finish | | | |
| Steeing wheel with Lock | | | |
| Floor | Skidproof rubber | | |
| Center sweater basket | Large volume, plastic | | |
| Golf bag holder | | | |
| Dashboard in black plastic | Forward/reverse switch, battery capacity indicator, ignition key | |
| Beverage holders | 4 cups drink holders | | |
| Glove box | | | |
| Side trim | Plastic |
| Score card holder | On steering wheel | | |
| Side rear view mirror | Two pieces per cart | | |
| Battery watering system,48V system | Without water supply tool |
| Battery watering system,36V system | Without water supply tool |
| Manual Pump | Water supply tool (other water supply tools are available) |
| Enclosure | | | |
| Electric system |
| Lighting system and horn | 2 headlights (with H/L beam), 2front turn signals, Front LED position light, 2LED taillights( each combined 1brake light with 1turn signal),with DC-DC converter (converting from 48V/36V to 12V), horn. |
| Reversing alarm | |
| Digital Meter | Speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator |
| Charger | China origin, onboard,input 110V-240V~50Hz-60Hz, output 36V/25A,48V/22A |
| Steering and Suspension |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | 4-wheel hydraulic drum brake +hand parking brake |
| 4-wheel hydraulic drum brake +EM brake |
| Rear wheel mechanical drum brake +EM brake |
| Accelerator | Stepless speed change |
| Suspension system | Front Independent Suspension and rear plate spring +cylinder hydraulic shock absorber |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Rear axle | Aluminum differential cage, Integrated, Gear ratio 12.76:1 | |
| Aluminum differential cage, Integrated, Gear ratio 10.26:1 | |
| Wheel &Tyre | 10x6 Alumimum wheel &205/50-10 4PR |
| 20.5*8-10 4PR |
