220V Hoisting Winch Cable Pulling Lifting Machine Electric Trolley

220V Hoisting winch cable pulling lifting machine electric trolley


Features of KCD Type Muliti-Function electric winch:

1.)Wire Rope Fixing: No escape of wire rope from the drum by means of P.T.screw device.
2.)Drum Transmission: The shaft direct friving drum provides rope replacement and alteration of rotation with easy.
3.)Electromagnetic: Designed for both static and dynamic loading. Brake will automatically apply in the event of power cut.Large friction surface area. No adjustments or serving requirement.
4.)Gear Box: Provides strength.durability and non-worry of breakage of structure.
5.)Special Motor: Insulated B,with the features of big start torque,small inertia,lower temperature rise,it can work frequenntly for a long time.
6.)Driving Gear: The heat treated gear with bearings features durable performance and anti-wear.
7.)Machine Fixture: It is made of super armor plate.used for suspender,lifter and girder.

Main Performances and Technical specifications of electric winch :

Model	KCD-300~600kg	KCD-500~1000kg	KCD-750~1500kg	KCD-1~2T
Capacity	600kg	1000kg	1500kg	2000kg
Lifting speed	7-14m/min	6-12m/min 8-16m/min	8-16m/min	8-16m/min
Power	0.6KW	1.5KW	2.0KW	3.0KW
Motor R.P.M	1380	1380	1380	1380
Voltage	380v	380v	380v	380v
Lifting height	60M	1-100M	100-150M	100-200M
Wire rope type	5.0*6*19	D-6*19-6	6*19*7.7	6*19*10
Weight	35kg	50kg	60kg	110kg

Packaging & Shipping:

Outside package: standard export wooden case or carton
Inside package: polybag
Or we can do as your requirements



Company Information:
As an company with over 15 years experience for exporting crane, Anlian has set up a perfect sales network and after-sales service system. With our rich experience, we can provide you a professional solution supporting and satisfied service.
Before order:
· Answering Customers' Questions: According to our customer's question by email or telephone, we will provide a patient and professional customer' service.
· Technology Guidance: Our cranes are all customized products, our sales manager will work together with our engineer provide a reasonable solution just for our customers condition.
· Product Recommendation: Huaige has totally over 100 products to fit our customers' various requirement. We will recommend sevral products according to the customer's requirement, such as application, the environment, working frequency and so on.
· Design Drawings: We will design drawings for customers' reference.
After order:
· Delievery Time: After signing the contract and recieving the depoist, the production will take 15~30 working days. Special standard making cost 5~10 more working days.
· Order Tracking: After the depoist recieved, there will be a professional team tracking the order from prodction to package and shipment.
· Crane Testing: All the materials are purchased from high quality supplier in China or the world, beyond this, we also make commissioning and test before packagement to avoid the trouble back.
After-sale Service:
Warranty Period: We provide 12 months warranty for main body. Also we will provide one group wearing parts for free.
Installation Service: Engineers will be arranged to provide installation service if customer need.


Trade:
MOQ:1 SetMini Electric Hoist
Port:Shanghai, Tianjing, Ningbo
Payment:L/C, T/T, Western or according to your requirements
Delivery Time:1~3 day after receiving deposit
Packaging:PE foam, plywood case
Shipping:By sea, by land or according to your requirments
Any Inquiry, please feel free to contact us!
