| Specifications | Model | EG2028KR |
| Key Components | Power Source | Pure Electric |
| Electric System | Both AC and DC system are available |
| Battery | Trojan battery |
| Motor | ADC motor or Chinese Motor |
| Controller | Curtis controller |
| Charger | China origin, input 110V-240V~50Hz-60Hz, |
| Performance | Passenger capacity | 2 |
| Range (loaded) based on flat road at aspeed of 20km/h (km) * | Up to 100 |
| Max.Speed | Up to 40 |
| Minimum turning radius (m) | 3.5 |
| Max.Climbing ability (loaded) | Up to 20% |
| Max.Movement after brake at speed of 20km/h | ≤4m |
| Max.Loading weight | 150kgs |
| Dimensions | Overall dimensions (mm) | 2400*1200*1850 |
| Min.Ground clearance (mm) | 120 |
| Wheelbase (mm) | 1700 |
| Front wheel tread (mm) | 855 |
| Rear wheel tread (mm) | 975 |
| Body and frame | frame | Welded steel framework with phosphate+electro-coating treatment |
| Body | PP plastic front body +PP plastic rear body |
| Roof | Fiberglass |
| Electric system | Lighting system and horn | Headlights,front turn signals, taillights, with DC-DC converter, horn,reversing alarm |
| Steering and Suspension | Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | 4-wheel hydraulic brake, front and rear drum brake, with hand parking brake |
| Suspension system | Front and rear plate spring +cylinder hydraulic shock absorber |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Rear axle | Integrated, Gear ratio12.49:1 for AC system and 10.25:1 for DC system |
| Wheel &Tyre | 10x6 Alumimum wheel &205/50-10 4PR |
| Option | Backrest cover in wood finish |
| Formed seat&backrest vinyl |
| Dashboard in wood finish |
| Steering wheel in wood finish |
| Glove box door (include two locks) in black plastic |
| Glove box door (include two locks) in wood finish (inside and outside) |
| 12V accessory plug |
| Hour meter |
| Front independent suspension, Rear Integrated Axle |
| On-board charger, input 85V~265V, 45~65Hz, output 36V/21A, 48V/18A |
| Body Color | Up to 6kinds of standard color for option |
| Loading | Both Assembly and Disassembly are available |
