SINOTRUK 6x4 Refrigerator Truck
1.USA Thero King Refrigerated System.
2. Quality Insulation Material
3,Heavy duty Loading Design
4,Suitable for food ,seafood,cold meat transportation.
5. Three free keypart for repair and replac
ement at one year.
Co
ntact Ms.Beria Huang+86-15507234243
Technique Parameters
Description | SINOTRUK 6x4 Refrigerator Truck |
| Drive Model | 6X4 |
| Vehicle Main Dimensions | Dimensions(L xW xH)mm | 12000*2500*3980 |
| Wheel base (mm) | 5825+1350 |
| Overhang (front/rear) (mm) | 1500/3286 |
| Wheel track (front/rear) (mm) | 2022/1830 |
| Approach/Departure angle(°) | 16/10 |
| Weight in KGS | Curb Weight | 12700 |
| GVW. | 25000 |
| Max. driving speed(km/h) | 90 |
| Chassis Model | ZZ1257 |
| Engine | Model | WD615.92 |
| Type | 4-stroke direct injection ,6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Horse Power(HP) | 266HP |
| Emission standard | Euro III |
| Gearbox | 10 forwards &1 reverse |
| Clutch | Reinforced diaphragm clutch |
| Steering Gear | Power steering, hydraulic steering with power assistance |
| Fuel tank (L) | 400 |
| Tire | 11.00-20, 10 pcs +1 spare tire |
| Brakes | dual circuit compssed air brake |
| Van body |
| Van Material | Double layer FRP(Glass Fiber Reinforced Plastics )
Stainless steel/Color plate can be chosen |
| Thermal insulation | 8CMpolyurethane foam |
| Body Overall Dimension | 8300*2300*2500mm |
| Door | Rear door open, side door is optional |
| Refrigerator unit brand | China HuaTai
Optional:China-Hanxue,America-Carrier/thermo,Korea Dongin, etc |
| Temperature | -5ºCor -18ºC as your choice |
Truck refrigerator
| Unit model | F800 |
| Refrigerator Type | HUATAI |
| Applicable temperature (ºC) | -18 |
| Applicable volume(m3) | 35 |
| Cooling capacity | Environmental
temperature | 0ºC | 8000 |
| -18ºC | 4200 |
| Voltage (V) | DC12V/24V |
| Current (A) | 27/17 |
| compssor | Displacement (cc/r) | 210 |
| condenser | Air flow (m3/h) | - |
| Fan type | - |
| number | - |
| evaporator | Air flow (m3/h) | - |
| Fan type | - |
| number | - |
| refrigerant | R404A |
| Refrigerant charge amount(Kg) | 3.1-3.2 |
| Defrost type | Hot gas defrost |
| Dimensions(mm) | evaporator | 1700×644×230 |
| Condensing utensil | 1565x555x415 |
| Weight(KG) | evaporator | 54.5 |
| Condensing utensil | 63.2 |
| Remark | Optional to install for 380v store electric power |
Our advantage:
· Competitive Price and Excellent Quality,
· More than 10 years' experience as amanufacturer,
· CCC,ISO,BV certification,
· Perfect after-sale service,
· Customized products available with us,
· Export covering More than 50 countries and regions ,
· Annual production value topped 1500,000,000 RMB (240,000,000 US dollars) per year.
CLW Heavy Industry Co.,Ltdis the branch company of Chengli Special Automobile Co.,Ltd.Chengli Special Automobile Co., Ltd, as the professio
nal manufacturer in the special vehicle circle,has developed into the biggest professio
nal special vehicle manufacturer of central China starting from scratch since 2004.
Chengli Special Automobile Co., Ltd Factory Supply:
a.special truck manufacturers in Suizhou city,HuBei province, china,
b.more than 300 kinds of special truck for your needing.such as refrigerator truck, garbage truck,LPG truck ,fuel truck ,water truck ,high platform truckdump truck ,co
ncrete mixer truck ,truck mounted crane ,chemical tank truck ,fire fighting truck ,bulk cement truck ,flat bed trailers ,low bed trailer ,cargo trailer tipper trailer ,fuel trailer ,LPG trailer and morec.Nearly 15 years experience in produce truck and truck parts field.
d. export turnover has reached 25million dollars and our products have been sold to more than 50 countries, including Africa ,Europe,Southeast Asia, Middle East, North Asia and so on.
Owing to our rich industrial experience,we are offering awide range of products to the customers, such as LPG tank, fuel tank, water truck, refrigerator truck,garbage truck and so on. We ensure to deliver those products at industry leading price range to meet the financial co
nstraints of our clients.
Our main products:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck
2. Water truck /Water Tank Truck /Water Sprinkler Truck/Water Tanker
3. Truck with crane /Truck mounted crane
4. Dump Truck /Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck /Fire Truck /Fire Vehicle
6. Co
ncrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck /Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck,sealed garbage truck
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer (flat bed trailer /skeleton trailer /dump semi trailer /side wall trailer /low bed trailer /van co
ntainer trailer /warehouse trailer, etc. )
More information oflpg truck, lpg tank truck, liquid petrol gas tank truck, please feel free to co
ntact withMs.Beria Huang tel: +8615507234243
We will customize the truck according to your requirement.sincerely welcome you to visit our factory and provide your pcious suggestion for us!
FAQ
1.Q:How a
bout quality of your factory quality ?
A:All our trucks 100% new .All our trucks got ISO 9001:2008 and CCC and B&V certificate ,and many truck passed SGS inspection .All our chassis and spare parts are from the original manufacturers with original part number and and anti-fake label, all our suppliershave passed the SGS,BV, and Co
nTECNA qualification certification, the quality is 100% guaranteed.
2.Q:How many years of your company's service, especially after-sale service?
A: Chengli special automobile Co.,Ltd has been in this field for nearly 15 years and has strong production and distribution capability,we can produce your products in 15 working days.We offer 1year service after -sale.
3.Q:Is there any advantages of your price?
A: ChengLi Special automobile Co.Ltd is one of the im
portant up date suppliers of Sinotruk and Shacman,Do
ngfeng ,FOTON ,FAW ,which provides guarantees for reaso
nable price and good quality. Meanwhile, other products are procured from our long time business partners, we also can be sure to provide competitive prices.
4. Price term: FOB, CIF
5. Payment: 30% deposit after order /con
firm/iation, 70% balance should be paid before delivery. All are by T/T, L/C.
6. Delivery time: 25 working days after payment is received.
7. Standard Steering: Left-hand drive, if you need Right-hand drives, please informus, will make special order for you.
Any question please co
ntact me without hesitation!!!
