Prebuilt Durable Modified Container House

New type pfabricated container house from China manufacturer

20ft/ 40ft container house/ container office (differenct designs according to customers requirements)

1. EPS and light weight, steel frame
2. Perfect supporting facilities
3. Long usage life
4. ISO and CE
5. Beautiful apperance

Founded in 2004, Hangzhou Xiaoya Prefabricated House Co, . Ltd. Is the first pfab house manufacture in zhejiang procince which have accumulated years experience in designing and manufacturing. Our main include: Container. House, pfabricated house, mobile environmental toilet, sentry box, light steel structure villa, etc, also, we provide housing customization services. More than 80% of our products are export globally, such as Australia, south America, Europe, America, South Africa, North Africa, Asia, Middle East, and other countries and regions


Container house:
1. Wall panel is EPS sandwich panel, insulation and light weight
2. Steel frame is galvanized and 2-3mm thickness, very strong
3. One side door is EPS sandwich panel with aluminum alloy frame

Features:
1. Safety and reliable light steel flexible stucture system.
2. Easy to transport, assemble and disassemble, repetitive to use
3. Good and attractive apperance
4. Water proof, sound insulated, heat pservation, easy to clean and maintenant
5. Any dimention and customized design are available
6. Widely used as office, dormitory, conference room, store, factory


Technical parameter of standard pfabricated house:
1. Wind resistance: Grade 11 (wind speed≤ 111.5km/h)
2. Earthquake resistance: Grade 7
3. Live load capacity of roofing: 0.5KN/m2
4. External and internal wall heat transmission coefficient: 0.35Kcal /m2hc
5. Second floor load capacity: 150kg/m2
6. Live load of corridor/ balcony/walkway is 2.0KN/m2
The whole LGS house system can be professional supplied under clients' design.


Flat-pack transportation
Plan One: A 20 foot container shipment for 4 sets of size 5850*2250*2640 container house
Plan two: A 40 foot container shipment for 7 sets of size 6055*2435*2640 container house

We will provide you full instruction manual and excellent after sale services. For special projects, we can also send our engineer to you to make sure you can move in with satisfaction
1. Lay foundation block on level ground
2 place container house base frame on foundation block
3. Install columns
4. Install roof frame
5. Install wall panels in accordance with the serial number
6. Finish wall panels installation

Xiaoya has always been committed to independent R D and studying advanced technology, exploring standardization, modularization and industrialization in architectural design.

Component	longbeam	3mmgalvanized
	shortbeam	2.5mmgalvanized
	column	3mmgalvanized
	wallpanel	75mmEPSsandwichboard
	roofpanel	75mmPUsandwichboard
	secondarybeam	Z-shapedgalvanizedsteeliron
	roofinsulation	75mmpolyurethane
	Floorpanel	18mmplywoodpanel+12mmlaminatedflooror 20mmcement-fiber+2mmPVC
	door	SteelSecuritydoor,740mmx1950mm
	window	PVCSlidingwindowwithRollingshutter,1100mmx800mm
	electronics,watersupply anddrainage	accordingtothelocallaw
	furnitureandappliance	Customized-madetoyourrequirements
