Fold Container House for Temporary Office / Prefabricated Building House for Labor Camp with Kitchen

Product Information:

ProductName	Container House
ModelNo.	KHC20
Material	Structure:Steel Wall:EPSsandwichpanel,rockwoodsandwichpanel,PUsandwichpanel Roof:EPSsandwichpanel,rockwoodsandwichpanel,PUsandwichpanel
Guarantee	6months,allmaterialscouldbecheckedbycustomerorthirdpartybeforedelivery.
Lifetime	about 25years
Mainoverseasmarket	Africa,Mid-east,Asia,SouthAmericaetc.
Feature	1,Lowfoundationcost,only300mmthickand400width 2,Easyandfastinstallation-4personalworkerscanfinish 100sqm/day. 3,Safety and reliable light steel flexible stucture system 4,Wind-proof,anti-rust,quake proof,termiteresisting 5.Anti-earthuake: 8grade 6.Temperature:-40 to 70 degree 7.Wind grade:8grade(the wind speed:20m/s)
TradeTerms	1,PricebaseonEXW,FOBGUANGZHOUORFOSHAN 2,Supplyability:30000sqm/month 3,MOQ:1set 4,Payment:T/Tpayment-30%beforeproduction,balance70%aftermaterialscheckandbeforedelivery,LCisavailable.
Certification	1,CertificationofISO9001 2,CertificationofSGS 3,CertificationofTUVRhineland

Structural Strength
Therr storeys high stacking, with the following design loads.
Floors: 250Kg/Sq. M
Roofs (of modules): 150Kg/Sq. M
Walkway: 500Kg/Sq. M
Stairs: 500Kg/Sq. M
Walls: Wind at 150 Km /Hour

Thermal insulation
Floor: 0.34W/Sq. M/° C
Walls: 0.20W/Sq. M/° C
Roofs: 0.30W/Sq. M/° C

Economic and environment ,fast installation ,convenient transport and storage
It can bu reused for many times .
Water-poof ,heat insulation , soundproof , corrosion-resistant

Be widely use : office house ,shop ,showroom ,guard house.school ,building worker's dormitory , warehouse , workshop etc.

Comparisonof different types of color steel sandwichpanel
	EPS sandwich panel	Rock wool sandwich panel	Glass wool color steel sandwich panel		PU(polyurethane) color steel sandwich panel
Thickness panel	50mm, 75mm, 100mm, 150mm	50mm, 75mm, 100mm, 150mm	50mm, 75mm, 100mm, 150mm		50mm, 75mm, 100mm, 150mm
Length of panel	custom-made	custom-made	custom-made		custom-made
Width of panel	950mm,960mm	950mm,960mm,1000mm	950mm,960mm,1000mm		950mm,960mm,1000mm
Density of core material	12kg/m 3 -15kg/m3	40kg/m3-120kg/m3	40kg/m3-120kg/m3		40kg/m3
Thickness of two sides color steel sheet	0.3mm-0.6mm	0.4mm-0.8mm	0.4mm-0.8mm		0.4mm-0.8mm
Fire resistance	N/L	A1		A1	B1
Insulation	0.032kal/meter.speed	N/L		N/L	0.0175kal/meter.speed
Advantage of sandwich panel	Light, low cost, water-resistance	fire-resistance, stable, multi-color choose, different style, warm, PU edge-sealing choosing		fire-resistance, stable, multi-color choose, different style, warm, PU edge-sealing choosing	fire-resistance, stable, multi-color choose, different style, warm PU edge-sealing choosing Insulation is best than others Suit to cold storage

Production time & Payment & Loading:
1) We accept TT, L/C Payment .
2) Get 30% deposite after 10-25days, the balance is paying before shipment.
3) All components are finished in our factory, then loading in container.
4) Every 40ft sea container can load 200-450Sqm house.
5) Trading Clause : FOB Price , CIF Price , CFR Price

Installation :
1) Clients need to do foundation after the order, based on our foundation drawing.
2) After container arrives on site, unload the goods, and assemble onsite. We provide assemble drawing.
3) We provide supervisor for extra charge if need.
4) Installation efficiency: about four skilled labors can assemble 40 sqm house in 8 hours without accessories.

Internal Display







Installation



Loading Container




our services:
(1). Professional design and engineering team: Full solution for site camp design. We could make the design for whole camp as per your requirement.
(2). Procurement and Manufacture for all material for pfabricated building. We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO/TUV/SGS standard, to make sure the fabrication works with high technology.
(3). Site management & Installation supervision, We could send our engineers to help for the installation supervision, you just need to ppare a team which know normal construction works will be OK.


Usage:
Homes, Residence, Accommodation, Hostel, Office, Reception house, Rest-room, Show-room, Public-accommodation, Place of recreation and so on.


Frequently Ask Questions

Q: Can I erect the frame myself?
A: Certainly you may erect the frame yourself. Please check the easy installation step as below. Many customers choose to do just that. However, many customers also choose to hire an experienced general contractor or framer to provide this service as well. The choice is up to you.

Q: Does it come with assembly instructions?
A: Yes. Your purchase of any pfab house comes complete with the drawing, installation instructions and installation videos.

Q: Will the steel in my frame rust?
A: Inside the walls and roof of a home or structure where the steel is not constantly wet your steel frame will be very resistant to rust and corrosion.
