Modular Flat Pack 40 FT Container House Shop for Merchandise Street

Description

Modular portable container house is designed according to specifications of shipping container exactly. It is made of pfab light steel as frame and sandwich panel for wall and roof, then facilitated with windows, doors, flooring, ceiling, and other additional accessories.They are fitted with power and lighting and can be accessorized to suit your requirements.
The house can be designed just as just one unit or connected to awhole from several boxes, by simple connection such as bolts. So it is easy and fast to be installed and disassembled. Save the time and money for you.

Wide Application

warehouse, storage, dormitory, kitchen, shower room, locker room, meeting room, classroom, shop, portable toilet,sentry box, mobile kiosk, motel, hotel, restaurant, and residential houses, temporary office, temporary hospital, dining-room, field and outdoor work station and so on.







Compare Container House And Common House

* Container house can beuse directly,no need installation, fast moving,can be reusedso very economical and environment-friendly.
* Prefabricated container house ischeaper,needs to be installed locally but very fast, usually a40HC container can hold 6-8 sets 6*2.5m pfab house.

Container House Advantages

Long life-span.up to 20 years.
Prefab,Pre installed electrical and plumbing,time saving.
Movable And Disassemble.Can be separately according to your requirements.Easy install, transport and relocate.
Economical and environment friendly.Short construction period and little workers, can be relocated with no waste.
Convenient transportation,can be transported as ashipping container, or flat packed.
High strength,Live load capacity of roofing: 0.5KN/m2. Second floor load capacity: 150kg/m2.Load bearing capacity greater than 40tons. Live load of corridor/ balcony/walkway is 2.0KN/m2
Waterproof, fireproof,seismic resist.Its wind resistance Grade 11 (wind speed≤ 111.5km/h) Earthquake resistance: Grade 7, External and internal wall heat transmission coefficient: 0.35Kcal /m2hc
Customizable.various design as per your pference.
Little requirements on ground.Being tough and flat is OK





Detailed Parameters

Size: GP20, GP40 and HP40 of shipping container
20ft portable container house specification: 6058mm*2438mm*2591mm
40ft portable container house specification: 12192mm*2438mm*2591mm
Customized dimension is welcome.Different size can be made by combine many container together.

20ft/ 40ftModular Portable Container House Specifications
External size	6058mm(L) *2438mm(W) *2591mm(H)/12116mm(L)*2438mm(W)*2591mm(H)
House corner	Prefabricated light steel
Roof panel	Rock Wool /EPS sandwich panel (according to customer requirement)
Wal panel	Rock Wool /EPS sandwich panel (according to customer requirement)
Ground base	Prefabricated light steel
Basic accessories	Window	PVC sliding windows or aluminium alloy window or plastic steel window
	Door	streel sandwich panel or aluminium frame sandwich panel door.
	False Ceiling	PVC ceiling
	Flooring	Plywood
	Electricity sys	2 lights &1 switch
Optional accessories	Furniture for housing living, office, dormitory, Toilet, Kitchen, Bathroom, Shower, Etc.

Purchase Suggests

1. The size you want,20' 40' or etc...
2. How many rooms do you need, bedroom, living room, kitchen, bathroom, toilet, balcony etc
3. Requirement of interior decorations etc

Packaging &Delivery

(1) Assembled loading and transportation
One 40ft HC load 2sets assembled container house with dimension- 5850mm*2250mm*2500mm
(2) Flat-pack transportation:
Plan A: One 20ft GP load 4sets 20 feet container houses
Plan B: One 40ft HC load 8sets 20 feet container house or 4sets 40 feet container house.
All panels are protected with PE film, and steel structure warped with woven belt. Accessories will be packed with paper box or plastic bags. Windows and doors will be packed with wooden box.




Installation service

* Layout plan can be designed if needed.
* Installation introduction /CD /installation drawing will be provided if needed.
* Engineers and workers can be sent abroad for guidance and installation.
All stuff have been pinstalled in the container and you just need put it on site ,connect to electricity and wate



about Us

1.Founded in the year of 2003,professional in various pfab houses and container houses and steel structure making.
2. More than 50 R&D staff andmore than 400 workers
3.35, 000 squarematers factory, full line production
4.Qualification:CE(DIN18800), ISO9001, BV, SGS; (CSA, AS/NZS, UL etc. )
5. High Construction Efficiency,delivery time will be within 20 to 30 days
