Detailed Description
2500 gallons suction truck, 10m3 vaccum suction truck
We're one specialist truck refitting and semi trailer manufacturer in China, we could supply various special purpose trucks and semi trailers. Our products are always popular in China several years.
From 2005, China allow exporting completed truck and semitrailer. We established overseas department that year and exported more than 30 counties prom
ptly. Our products got almost clients' love and admiration. We appciate our clients' fully trust to us, and remember the respo
nsibility every moment.
There're too much processes need to do during producing, we never dare to reduce anyone. And we never dare to reduce any material although it's expensive. All of these o
nly for ensure the high quality and excellent performance.
Respectful,Faithful,Studious,Innovative .Our progress never could leave your supporting. Warmly welcome your coming!
Vacuum sewage suction truck could be used to suction waste water, little stone, sand, mud, animal and vegetable oil, solid materials as well as human waste. the hydraulic vacuum system able to suction and discharge that kind of materials.
| Item | Parameter |
| Model: | CA5111XXYPK2L3EA80-3Fecal Suction Truck |
| Overall dimensions | 10275×2305×2600mm |
| Produced by | QINGDAO HETANCH TRUCK CO.,LTD |
| Cabin | FAW J5K with A/C, LHD |
| Wheel base | 4970mm |
| Engine Model | CA6DF3-18E3FEURO 2, 180HP |
| Gearbox | CA6TBX075M, 6Forward Speeds |
| Clutch | 380mm |
| Website | www.sinohtc.com |
| Rear axle | 435(rate: 5.571) |
| Tyre | 9.00R20-16 Radial tyre |
| Max speed | 83km/h |
| Max overall weight | 16990kg |
| Rated load weight | 9990kg |
| Curb weight | 7000kg |
| Tanker | Volume | 2500 Gallons |
| Material | Carbon steel |
| Thickness | 4mm/ 5mm |
| Vacuum Pump | Quick suction and discharge |
| Hose | Wire strengthened hose |
| Rear door | Opened by hydraulic cylinder |
| Accessories | Anti-fill valve, level indicator, inlet, discharge, high quality suction hose |
We also could supply more models with different tanker volume. And the truck chassis could be used DONGFENG, SINOTRUK and SHACMAN. The driving type have 4x2, 4x4 and 6x2, 6x4. More details, feel free to co
ntact us please.
Tel: +86-135-5300-6067
Website: www.sinohtc.com
Product Image
