Detailed Description
Multi-Function Sewage Suction Truck and High Pressure Cleaning Truck
Company information:
We're one professio
nal manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as dump truck, tanker trailer, co
ncrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.
We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to co
ntact us please.
| Specification of the sewage suction truck |
| Items | Descriptions | Specifications and Types |
| General | Truck Name | Sewage suction truck |
| Drive Type | 4*2 |
| Gross Vehicle Weight(kg) | 4495 |
| Curb Weight (kg) | 2865 |
| Overall Dimensions L*W*H(mm) | 5880*1920*2450 |
| Engine | Engine Model | YC4102-CE4F |
| Engine Brand | CHAOCHAI |
| Fuel Type | Diesel |
| Power | 73kw/99HP |
| Emission Standard | Euro IV |
| Displacement(ml) | 3298 |
| Engine Type | 4 cylinders in line,water cooling, turbo-charged diesel engine,inter-cooling |
| Chassis | Chassis Brand | Dongfeng |
| Front/Rear Axle Load(KG) | 1800/2695 |
| Tire No. | 6 |
| Tire Specification | 7.00-16 |
| Wheelbase (mm) | 3300 |
| Axle No. | 2 |
| Gear Box | 5 speed forward with 1 reverse, manual |
| Steering Wheel | Left hand drive with power-assisted |
| Brake | Air brake |
| Radiator | Suitable for tropical climate |
| Sucking System | Sewage tank Volume(L) | 3000 |
| Tank shape | 6000 |
| Tank Material | 5mm thick carbon steel |
| Suction Depth(m) | More than 6 meter |
| Tank Tipping angle(°) | More than 45 |
| Rear door | Open and closed by hydraulic cylinders |
Product Image
