316L IBC Tank Container 1000liter

We offer arange of stainless steel IBCs for storage, handling, and transportation of products anywhere in the European Union, and to an increasing number of global locations. Our IBCs are suitable for awide range of uses, including hazardous and non-hazardous, heated and cooled, chemicals and petrochemicals, pharmaceutical intermediates, cosmetics and personal care, food ingredients


316l IBC TANK CONTAINER

A UN approval from CCS and BV
B Manufature with ISO 9001
C Design- IMDG 2008

STAINLESS STEEL PREMIER IBC SPECIFICATIONS

Material: 10 gauge type 304 stainless steel top, bottom &shell

Material Finish: 2B rolled finish

Interior Weld Finish: As laid with discoloration removed, cleaned of all weld slag and splatter.

Exterior Weld Finish: All welds to be continuous with discoloration removed, cleaned of all weld slag and splatter.

Manway: Nominal 22-1/2" drum cover/3" nipple with EPDM gasket, plated carbon steel clamp ring bolt and nut

Fusible Device: 3" fusible device with Teflon gasket mounted in center of lid

Nozzles: Top of tank to have (1) 2" diameter bung w/ plug &Buna-N gasketLifting Lugs: Four (4) "off

Shore" lifting lugs/leg positioners to allow stacking as well as lifting from overhead

Decals: Caution do not pssurize, No forks this side, Valve open-closed, Vent tank prior to discharge

Bottom Design: 1" one piece sloped bottom for virtual 100% drainage

Support Legs: 5-1/2" snag resistant support legs for lift truck handling

Discharge: 2" diameter ball valve with lockable handle and polymeric shipping seal
Valve Guard: Full length valve protection guard

DOT/UN: Tested and tagged per DOT Title 49 specifications 31A/Y

Replacement Parts Also Available
ApprovalIMDG UN31A/Y
Container wall material 304
Sealing material EPDM
Suitable Suitable for liquid hazardous goods, of density less then or equal RO 2.0 of the UN II, III group
Outlet valve Butterfly valve/ball valve
Safety calve Pressure setting 0.21bar
