10 Tons sewage suction tanker truck, 4X2 sewage suction tank truck

10 Tons sewage suction tanker truck, 4x2 sewage suction tank truck
5-10 cbm sewage truck,Vacuum Suction Truck,suction sewage truck

We're one specialist truck refitting and semi trailer manufacturer in China, we could supply various special purpose trucks and semi trailers. Our products are always popular in China several years.

From 2005, China allow exporting completed truck and semitrailer. We established overseas department that year and exported more than 30 counties promptly. Our products got almost clients' love and admiration. We appciate our clients' fully trust to us, and remember the responsibility every moment.

There're too much processes need to do during producing, we never dare to reduce anyone. And we never dare to reduce any material although it's expensive. All of these only for ensure the high quality and excellent performance.

Respectful,Faithful,Studious,Innovative .Our progress never could leave your supporting. Warmly welcome your coming!







We're expert for supply variousSpecialized Vehicle, such as sprinkler truck, wrecker truck, garbage truck,fire fighting truck, refuel truck, crane truck,Sewage Suction Truck, and so on. The followed is5-10 cbm Sewage & Fecal Suction Truck specification:

Features
1. Adopt the Fonton designed mature dump truck chassis to install of Sewage tank, Vacuum pump, Four-way valve, Anti-overflow valve, Pipeline system and so on. The layout is reasonable and easy to operate.
2. High pumping efficiency, easy to operate, low fuel consumption, big power, low cost, one machine for Multi-purpose.

3. With self-absorption and self-discharging function, Pumping full time is less than 5 min, Suction length is more than 8m.
4. Sewage vacuum truck is mainly used for sucking septic tanks of neighbourhood, factory, school and household, it can also be used for cleaning the sewer sediments of city, dredging drains, watering, carrying water, green, fire fighting, drought fighting, one machine for Multi-purpose.

Notice Model: HTC5120GXWB
Chassis Model: CA1169
Front suspension/ Rear suspension (mm): 1100/2000, 1100/2050
Engine power(KW): 68/67
Number of axes: 2
Wheelbase: 4700, 4800
Tyre Specifications: 9.00-16, 10.00R20-16, 9.00R16
Fuel type: Diesel fuel.

Emission standards: GB17691-2005 Europe III, GB3847-2005
Exterior Size(mm) length*width* height: 6500, 6350*2080*2550
Tank Size (Tank length*longer axis*shorter axis): 3300*1700*1200
Suction depth: >8m
Load capatity: 10000
Engine: CA6dl-18
Engine manufacturers: FAW Xichai Machinery Co., Ltd.

Brand	FAW
Driving	4x2
Volume	8000-10000 liters
