100L Laboratory Fermentation Tank (ACE-FJG-W2)

100L Laboratory Fermentation Tank (ACE-FJG-W2)

Fermenter available from 1 Barrel to 100 Barrels with an average 25% Head Space. All tank have a

Dish top , Cylinder body & 60 /70° Cone Bottom. Certifiedstainless steel material for all tanks,

with 100% TIG welded joints and seams withsanitary interior polish. Dimple Plate jacket for

Glycol cooling & high efficient Polyurethane foam insulated. All tanks use Tri-clamp connections,

aredesigned for up to 14.7 PSI and tested at 30 PSI. We can custom fabricateany tank to meet

your brewery's space and height restrictions.

NAME BRAND, HIGH QUALITY VALVES AND FITTINGS WITH EVERY TANK!

Standard Features:

•Dual zone dimple cooling jackets (3 or more on larger tanks)

•Interior shell: 304 stainless steel, thickness 3mm /11 gauge

•Cooling jacket: 304 stainless steel, thickness 2mm /14 gauge

•Exterior shell: 304 stainless steel, thickness 2mm /14 gauge

•2" Polyurethane insulation

•Interior surface to finish pickled and passivated

•Exterior surface to brushed, #4 finish

•580x480mm Side manway, shadowless

•Dry hop inlet at top;

•Accessories:

Sample Valve x1;

Pressure relief/vacuum valve x1;

Temp. sensor / thermometer x1;

Rotating racking arm with butterfly valve x1;

Bottom outlet with butterfly valve x1;

Spraying Ball with down tube x1;

Stainless pipe legs with adjustable footpads x4;

Pre-sale service:

1. Free of making offers, craft and technical guidance of our products.

If you are interested in any product, please contact us without hesitation. We will give a quote to you, and give you all the details you need at first time.

2. We can provide company's qualification certification and the drawings.

3. We can also make customized products according to customer's needs.We accept OEM production. You can inform us of what you need. We'll make our best to make you happy.

After-sale service:

1. We provide long-term after-sale service,the service after-sale is same important for us.

2. Owing to the quotation of our equipment is FOB price except charges of door-to-door service. Thus, if necessary, we can appoint our technician to debug the machine with air ticket, visa, accommodation and labor cost provided by your party. Or you can send your technician to our company to learn techniques.

3. Meanwhile, you can call or E-mail to consult any relevant questions since we have a special line of after-sale service. Or you can communicate online and solve the problems.
