FAW Concrete Mixer Truck price, Concrete Mixer Truck for sale

FAW 10cbm Concrete Mixer Truck

We're one specialist truck refitting and semi trailer manufacturer in China, we could supply various special purpose trucks and semi trailers. Our products are always popular in China several years.

From 2005, China allow exporting completed truck and semitrailer. We established overseas department that year and exported more than 30 counties promptly. Our products got almost clients' love and admiration. We appciate our clients' fully trust to us, and remember the responsibility every moment.

There're too much processes need to do during producing, we never dare to reduce anyone. And we never dare to reduce any material although it's expensive. All of these only for ensure the high quality and excellent performance.

Respectful,Faithful,Studious,Innovative .Our progress never could leave your supporting. Warmly welcome your coming!




Chassis J5P Cabin with A/C
Emission Rating Euro-3.
Wheel formular/drive wheels 6× 4 / rear
Overall Vehicle (mm)
Length 9180
Width 2496
Height 3755
Wheelbase (mm) 3800+1350
Track F/R (mm) 1493 / 2537
Curb Weight (kg) 13240
Gross Vehicle Weight (kg) 34990
Max. Speed 86

Engine:
Trade mark, model WP10.336N 336HP
Transmission Fuller RTD-11509C
Tire 11.00R20
Drum
Diameter of the drum (mm) Φ 2340
Available capacity (M3) 10
Material Discharged Remaining Ration (%); 1
Thickness of Drum(mm) 4.5
Thickness of Blade(mm) 4
Hydraulic system
Reduction gear ZF P7300
Oil pump Eaton 6423-279
Motor Eaton 6433-042
Water washing system is driven by air pssure
Water Tank Volume (L) 300L. 400L

NOTE:
We are a leading special purpose vehicle & vehicle body manuifacturer from China, our products: Refrigerated truck & body, Insulated truck & body, Dry cargo truck & body, Store/stake truck & body, Explosion-proof truck & body, Dump truck & body, Truck crane & body, Mobile catering truck & body, Mobile stage truck & body, Mobile shop, Mobile kitchen, Cargo van, Medical waste transport truck & body, Box trailer, etc.

Q: How can we trust your company?

A: We are the official authority company by FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us.

Q: Can u provide the ISO9001 certificate or some others related?

A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.

Q: How about warranty item?

A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.

Chassis	Brand		FAW
	Chassis model		CA5250P66K2L1T1S2E
	Drive model		6*4
	Tire		11.00-20
	Brake		Air brake
Engine	Model		CA6DL2-35E3F
	Horse Power		350
	Displacement(ml)/Power(kw)		8600/261
	Emission		Euro III
Main Parameter	Overrall dimension(MM)	L*W*H	9210*2495*3900
		wheelbase	3800+1350
		Axles No.	3
	weight	GVW	25000
		Payload weight	10280
		Curb weight	14590
	Leaf spring No.		12/12
	Approaching/Departure Angle(°)		24/18
	Front/Rear trace(mm)		2050
	Front/Rear suspension(mm)		1830/1830
	Max speed(km/h)		88
	Gear box		9speed
	Front/Rear Axle Load		7/16T
Technical Paratmeters of Mixing Tube	Tube Geometric Volume(M³)		12
	Mixing Volume(M³)		10
	Filling Rate(%)		58%
	Rate of Feeding(M³/min)		≥3
	Rate of Delivery(M³/min)		≥2.0
	The Remaining Rate(Ml³/min)		≤1.0
	Tube Service Speed(r/min)		0~12
	Tube Dip(°)		13~15
Hydraulic Drive Paratmeners	Oil Pump		import from Italy
	Hydraulic Motors
	Decelerator
