Heavy Duty Selective Pallet Racking From Jiangsu Nova

Structural feature:

1. VNA pallet racking refers to the pallet racking system for which three-direction forklifts are used.

2. The major difference of VNA racking from regular pallet racking is that the width of the VNA racking aisle (usually 1600-2000mm) is much narrower than that of the regular pallet racking system, which makes better use of storage space by 20%.

3. Guide rails are needed to be fixed at the two sides of the aisle to guide the forklift.
Model: NH heavy duty VNA racking

Specification:
UPRINGHT: NH1 TYPE (80 TYPE), NH2A TYPE(90A TYPE), NH2B TYPE(90B TYPE), NH3 TYPE(100 TYPE)
NH4 TYPE(120 TYPE), NH5 TYPE(140 TYPE), NH6 TYPE(160 TYPE)
The non-standard ones can be customized based on clients' requirements.

Beams are divided into Box beams and Step beams
Sectional sizes of box beams include: Y80, Y100, Y110, Y120, Y140, Y160,K180
Sectional sizes of step beams include: PK80, PK100, PK125

frame	Height (2-13m)	Depth (600-1,400mm)
	Upright section: 80x60; 90 x 70; 100 x 65; 120x87mm
	Thickness: 2.0/2.3/2.5/3.0mm
Beam	Length (1200-4000mm) , popular size: 2300,2500,2700,3200,3600mm
	Beam section: 80 x 50; 100 x 50;110x50; 120 x 50; 140 x 50mm
	Thickness: 1.4--1.5mm
Load capacity	1-4Tons/Layer
Others	Pitch: 75mm,76.2mm - Delivery time: 14-20days - Payment term. T/T or L/C at sight - Necessary accessories: free(bolts & nuts, base plate, etc) - Packing:stretch film & carton - Surface treatment: powder coated, galvanization - Production capacity:3000T/month - Main market: exported more than 40countries, such as AU, PH, SG,UK, INDIAand etc. - Available in various colors/specifications/sizes

Route:

Our office and factory are located in Nanjing, Jiangsu Province, China,
1) You can fly to Nanjing Airport directly. We will pick you up on Nanjing Lukou International airport;

2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in Nanjing South Railway Station.

Welcome you to our comoany.

AFQ;

1. What makes you differentwith others?

1) Our Excellent Service

For a quick, no hassle quote just send email to us

We promise to reply with a price within 24 hours - sometimes even within the hour.

If you need an advice, just call our export office at 0086-25-51873961, we will answer your questions immediately.

2)Our quick manufacturing time

For Normal orders, we will promise to produce within15 days.

As a manufactory, we can essure the delivery time according to the formal contract.

3)Our Special Export Design

We pay very much attention to the export packages. We have plastic clips on the beams to protect the beams from surface damage in the transportation, We have got the whole uprights wrapped with transparent plastic film.

4)Our Warranty Time

The High Standards in the Design and Manufacturing ensure us to supportthe products with a 10-Year Warranty Time for your normaluse, it is the Longest Manufacturer's Warranty !

2. Whatis delivery times?

This depends on the product. Typically standard products are delivered within 20 days.

The delivery time of the special products is according to the time of setting up of the tooling.

3.Whatis the term of payment?

1) T/T payment.2) LC

4. May I know the status of my order?

Yes .We will send you information and photos at different production stage of your order. You will get the latest information in time.

5. Are samples available?

Yes, we can send some sections of samples for your reference by expss.

We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.
